With such a small form factor, Pad-Ex® 01 P8 DZ2 complies with IP64, 4 feet drop, and MIL-STD 810G for vibration. With added display protection, it provides total protection against the harsh environment encountered by field workers and alleviates strain on their bodies over long hours of work.
As private 4G / LTE wireless communication becomes more prevalent in hazardous locations, Pad-Ex® 01 P8 DZ2 ensures rapid and seamless access – allowing users to swiftly acquire the information necessary to complete the task at hand. For field locations without WiFi or 4G connectivity, the Pad-Ex® 01 P8 DZ2 offers up to 256GB of SSD memory to suit your onboard data storage requirements, underpinned by an i5 processor to guarantee your applications function as smoothly and effectively as possible.
Pad-Ex® 01 P8 DZ2 also supports the latest Bluetooth standards, enabling real-time connectivity to both Bluetooth SmartReady Low Energy 5.0 (BLE) and traditional Bluetooth devices. This enables the mobile worker to take advantage of extended Pad-Ex® 01 P8 DZ2 features, including data gathering and measurement/monitoring devices, headphones, AutoID, and Bluetooth Beacons for location.
When you’re finished with your field job, the Pad-Ex® 01 P8 DZ2 changes into a PC via the optional desktop docking adapter, allowing for easy connectivity with your office and corporate networks.
Features:
- ATEX Zone 2
- ATEX Zone 22
- Class I Division II
- IECEx
- Windows® 10 Pro 64-bit
- 8th Generation Intel® Core™ Processor
- 1920×1080: High Resolution Display
- 11.6″ widescreen display
- Sunlight Readable Display
- Capacitive Multi-Touch Screen
- Bluetooth 5.0
- Support 4G LTE
- Support GPS / Augmented Reality
- Intel Wireless AC9260 802.11 a/b/g/n/ac
- 5 MP rear / 2 MP front
- 1D / 2D Barcode Scanner (optional)
- IP 65
Specifications:
| RUGGED FEATURES | |
| IP65 DROP | MIL-STD 810G 516.6 Procedure IV |
| 6 drops from 4 feet height to plywood over concrete | |
| VIBRATION | MIL-STD 810G 514.6 Procedure I Cat. 24, |
| Fig. 514.6E-1 | |
| ENVIRONMENT TEMPERATURE | Operating: -10°C - 55°C (14°F - 131°F) |
| Storage: -10°C - 55°C (14°F - 131°F) | |
| HUMIDITY | Operating: 5% - 95% |
| ALTITUDE | Operating: 15,000 feet (approx. 4,572 m) |
| TECHNICAL FEATURES | |
| OPERATING SYSTEM | Full Windows 10 64 Bit / Windows 10 Pro |
| CPU | Intel Broadwell i5 series |
| MEMORY | One DDR4 socket for 8GB |
| STORAGE | M2-SATA SSD 256GB |
| DISPLAY | 11.6" HD (1920 x 1080) LCD Panel |
| Capacitive Multi-Touch | |
| Optical Bonding Sunlight Readable LCD | |
| Ambient Light Sensor | |
| SENSOR | Built-in G sensor, Gyroscope, and E-Compass |
| AUDIO | Integrated speaker x 1 |
| Integrated microphone - Intel® High Definition Audio Compliant | |
| CAMERA | 2MP Front Facing Camera |
| 5MP Rear Camera with auto focus and LED flashlight | |
| support Geo Tagging (Optional) | |
| COMMUNICATION | 4G LTE (Optional) |
| GPS (Optional) | |
| Intel Wireless AC9260 802.11 a/b/g/n/ac | |
| Bluetooth 5.0 | |
| DATA COLLECTION | 1D / 2D Barcode Scanner (Optional) |
| VO PORTS | Two USB 3.0 |
| One Headphone out / Mic-in jack | |
| One Docking Connector | |
| One Expansion Connector for Expansion Modules | |
| Two RF pass-through connectors for WWAN & GPS | |
| EXPANSION SLOTS | One Micro SD Card slot support SDHC & SDXC |
| One SIM Card | |
| BUTTON | Power |
| Volume | |
| Windows Touch button | |
| Barcode / Camera Touch Button | |
| Programmable Touch Button | |
| BATTERY | One 3,950 mAh Li-Polymer battery pack: 7hrs |
| 7,800 mAh (Optional) Li-Polymer battery pack: 14hrs | |
| AC ADAPTOR | 19 V; 3,42 A; 65 W |
| DIMENSION | 298 mm x 192 mm x 20 mm (11.75" x 7.55" x 0.78") |
| WEIGHT | 1.2 Kg (~42.32 oz) |
