| Global (IECEx) | IECEx CQM 19.0013X |
| Gas and dust | Ex db eb op is IIC T6 Gb1);
Ex db eb q op is IIC T5 or T6 Gb1); Ex tb op is IIIC T80℃ Db IP661) |
| Europe (ATEX) | CML. 19 ATEX 1288X |
| Gas and dust |  II 2 G Ex db eb op is IIC T6 Gb1)
|
| Certificates | IECEx; ATEX; CU-TR |
| Conformity to standards | EN; IEC |
| Degree of protection | IP66/IP67 |
| Ambient temperature | Ex db eb op T6: -40℃~+45℃;
Ex db eb q op T5/T6: -40℃~+55℃; Ex tb op is IIIC T80℃ :-40℃~+55℃ |
| Material | GRP, stands 7J impact, corrosion-proof
Polycarbonate, high light transmission, stands 7J impact |
| Weight | 7.4~14.75kg |
| Dimensions | 1380x222x134mm |
| Lamp specification | LED module |
| Lamp power (W) | 28W/18W/14W/9W x 2； 28W/18W/14W/9W x 1 |
| Emergency power (W) | 28W/14W x 1 |
| Emergency starting time | 0.3s |
| Charging time | 24h |
| Emergency lighting time | 120 min/180min |
| Rated voltage | 100~277V AC 50/60Hz;170~264V AC 50/60Hz;200~250V DC |
| Rated luminous flux | 910~5770lm |
| Terminal | 3 x 1.5~4mm2 (L+N+PE) |
| Cable entries | 4 |
| Available cable outer diameter | Φ9~Φ16 (mm) |
