Durabook U11 C1D2-11 Pro Rugged Tablet

In StockSKU: —

Version

$3,170.00

Qty

Safety Specifications

Safety specifications not available for this product

Product Description

The DURABOOK U11 G3 is a rugged 11.6″ Windows 11 tablet engineered for the extreme demands of oil & gas and industrial environments, featuring C1D2 certification and 12th Gen Intel® processing power. Built to endure, it combines a 6-foot drop rating with an IP66-certified fanless design for reliable performance in hazardous locations, MIL-STD-810H certification, an 11.6” FHD DynaVue® display, and an ultra-long battery life of up to 20 hours.

Technical Datasheet

Certification & Specification

Country of Origin

Taiwan (TW)

Product Overview

Durabook U11 C1D2-11 Pro Rugged Tablet

Introducing the Durabook U11 Window-11 Pro Rugged Tablet, a rugged tablet designed for uncompromising performance in extreme environments. This MIL-STD-810H certified device can withstand a 6-foot drop and holds an IP66 rating, providing maximum protection against dust, dirt, and water ingress. Its rock-solid design ensures durability, allowing operation in temperatures ranging from -4°F to 140°F.

Experience an exceptional viewing journey with the U11I 11.6″ FHD LCD, featuring DynaVue® sunlight-readable technology for detailed viewing even in direct sunlight. Boasting 1,000-nit brightness, the display offers enhanced clarity, complemented by a 10-point capacitive multi-touch panel with four advanced touch modes, accommodating various input preferences regardless of working conditions.

Powered by a compact yet robust build, the U11-EX doesn't compromise on functionality. Enjoy an ultra-long battery life of up to 10 hours, with the option to extend it to 20 hours with a high-capacity battery. This extended operational capability makes the U11-EX the perfect device for those who work outside traditional office settings, ensuring reliable and uninterrupted productivity.

Features:

ANSI Class 1 Division 2
MIL-STD-461G
MIL-STD 810G
IP66 Certified
6 ft drop
11.6” FHD DynaVue® SR display with 1000 nits
12th Generation Intel® Core™ Processor
Multiple I/O options for various applications
10 Hr battery and an optional 20 Hr Hi-Cap hot-swappable battery
Fanless and quick-release SSD design
10-point capacitive multi-touch panel with four touch modes

Superb Performance Built-in

The U11 C1D2 boasts superb performance with its 12th Gen Intel® CPU processor, complemented by Intel® Iris® Xe Graphics and various architectural innovations. This 11-inch rugged tablet stands out by surpassing standard requirements, delivering an elevated experience for professional users. Its advanced wired and wireless transmission capabilities, including Thunderbolt 4, 5G, 4G LTE, GPS, Intel® WI-FI 6E, and Bluetooth® V5.3, ensure smooth and congestion-free data processing at all times. Additionally, the tablet features a 2MP front camera and offers optional upgrades like a Windows Hello face-authentication camera and an 8MP rear camera, enhancing its versatility for a wide range of applications.

ANSI/UL 121201 CERTIFIED

The U11 is ANSI/UL 121201 C1D2 certified, ensuring its safety for use in potentially explosive atmospheres. This fully rugged tablet empowers frontline professionals with the confidence to provide remote support, access critical information, and run diagnostics with utmost accuracy in hazardous environments.

COOLFINITY™ FANLESS DESIGN

The U11 C1D2 boasts a Coolfinity™ fanless design, ensuring quiet operation, increased reliability, and reduced downtime. This innovative thermal solution is unique in its class, making the 11.6” rugged tablet ideal for industries where standard computers may struggle. It provides an extra level of security for the mobile workforce, enhancing performance without the need for a traditional cooling fan.

Rock-Solid Design:

Built for extreme environments, the U11-EX is MIL-STD-810H certified, capable of withstanding a 6-foot drop, and boasting an IP66 rating for protection against dust, dirt, and water ingress. Its robust design ensures endurance, with the ability to operate in temperatures ranging from -4°F to 140°F.

Exceptional Viewing Experience:

The U11I-EX features an 11.6″ FHD LCD with DynaVue® sunlight-readable technology, providing detailed viewing even in direct sunlight. With 1,000-nit brightness, the display offers enhanced clarity. The 10-point capacitive multi-touch panel features four advanced touch modes, accommodating various input preferences, including finger, glove, or stylus, and ensuring functionality in all conditions, even when the display is wet.

Long-Life Battery Time:

Compact yet powerful, the U11I-EX ensures functionality without compromise. With an ultra-long battery life of up to 10 hours and the option for a high-capacity battery lasting up to 20 hours, this rugged tablet offers versatility and non-stop operation with a single battery. Ideal for those working outside traditional offices, its extended battery life makes it a reliable device for sustained productivity.

Durabook U11 C1D2 Window-11 Pro Tablet

Specifications:

DURABILITY	• MIL-STD 810H certified (Drop, Shock, Vibration, Rain, Dust, Altitude, Freeze/Thaw, High/Low Temperature, Temperature Shock, Humidity, Explosive Atmosphere, Salt Fog)
	• MIL-STD 461G certified (Conduction, Radiation, Conducted Susceptibility, Radiated Susceptibility) • Optional ANSI/UL 121201, Class I, Division 2
	• 6' drop 26 faces • IP 66 certified • Aluminum-magnesium alloy chassis • Port covers • Optional sunlight readable display • Optional swappable battery technology
Operating System	Windows® 11 Pro 64-bit
Processors	• Intel® Core™ i7-1250U (12th Gen) Processor with vPro™ (12MB Cache, up to 4.7 GHz, 2P+8E cores)
	• Intel® Core™ i5-1230U (12th Gen) Processor with vPro™ (12MB Cache, up to 4.4 GHz, 2P+8E cores)
GRAPHICS	Intel® Iris® Xe Graphics
Memory	Onboard 8GB up to 32GB (LPDDR4x)
Storage	256GB NVME PCIE SSD
	• Optional 512GB/1TB/2TB PCIE SSD
	• Optional OPAL 2.0 SSD
DISPLAY	11.6” FHD (1920 × 1080) • Optional 1000 nits DynaVue® sunlight readable display with capacitive multi-touch screen • Optional with digitizer • User selectable touch mode for Finger/Water, Glove or Stylus programmable function
AUDIO	• Integrated microphone • Intel® High Definition Audio Compliant • Integrated speaker × 2
CAMERA	• Integrated 2.0 MP front-facing camera • Optional 8.0 MP auto-focus rear camera with flash • Optional IR camera for Windows Hello face authentication
KEYBOARD & INPUT	5 buttons (2 user-definable keys)
COMMUNICATIONS	• Integrated 10/100/1000 Ethernet • Intel® Wi-Fi 6E AX211 (802.11ax) • Bluetooth® V5.3 • Optional dedicated GPS module (UBLOX-NEO-M9N)1 • Optional 4G LTE multi-carrier mobile broadband1 • Optional 5G (project based)1 • Optional RF antenna pass-through for GPS, WWAN, and WLAN
SECURITY	• Intel® vPro™ Technology • Secured-Core PC2 • TPM 2.0 • NIST BIOS compliant • Easy removable SSD • Stealth mode • Kensington lock • Optional smart card reader x 1 or x 22,3 • Optional Windows Hello • Optional night vision mode4 • Optional fingerprint scanner • Optional LF/HF-RFID (NFC) reader2,3
I/O INTERFACES	• Thunderbolt 4 x 1 • USB 3.2 Gen1 (type A) x 1 • Audio in/out (combo jack) x 1 • microSD card (microSDHC, microSDXC) x 1 • 10/100/1000 Ethernet (RJ45) x 1 • Docking connector (20-pin Pogo) x 1 • Nano SIM card x 1 • DC-In jack x 1 • Optional smart card reader x 1 or x 22,3 • Optional USB 3.2 Gen2 (type C) x 15 • Optional 2nd USB 3.2 Gen1 (type A) x 15 • Optional USB 2.0 (type A) x 15 • Optional serial port (RS232, 422 and 485 : D-sub,9-pin) x 15 • Optional 1D/2D barcode reader x 15 • Optional RF antenna pass-through for GPS, WWAN and WLAN
EXPANSION SLOT	Optional PCMCIA Type II or ExpressCard 54 or LF/HF-RFID (NFC) or 2nd smart card reader3
POWER	AC adapter : 100-240V, 50Hz-60Hz, 65W Main battery: Li-Ion, 7.6V, 4800mAh, 10 hours6
	• Optional hi-cap battery Li-Ion 7.6V, 9600mAh, 20 hours6
	• Optional bridge battery : 5 minutes swap time7
ENVIRONMENT	• Temperature
	Operating : - 20°C ~ 60°C / - 4°F ~ 140°F
	Storage : -51°C ~ 71°C / -60°F ~ 160°F
	• Humidity : 5% ~ 95%
DIMENSION & WEIGHT	• 12.48” (L) x 8.47”(W) x 0.94” (H)
	• 2.99lbs
WARRANTY	3-year Accidental Damage Warranty

Durabook U11 Window-11 Pro Tablet

Description versions:

Durabook U11-C1D2-Standard SR: 11.6" FHD (1920 x1080) Sunlight Readable 1000 nits Touchscreen Display, Intel® Core™ i5-1230U vPro Processor up to 4.4 GHz, Windows 11 Professional with 8GB RAM, 256GB PCIe SSD, Bridge Battery, Wi-Fi 6E + Bluetooth v5.3, 2MP Front Camera, 8MP Rear Camera, USB 3.2 Type A x2 + Thunderbolt 4, IP66, 3-Year Durabook Accidental Damage Warranty Coverage

Durabook U11-C1D2-Field: 11.6" FHD (1920 x1080) Sunlight Readable 1000 nits Touchscreen Display, Intel® Core™ i5-1230U vPro Processor up to 4.4 GHz, Windows 11 Professional with 8GB RAM, 256GB PCIe SSD, Bridge Battery, Wi-Fi 6E + Bluetooth v5.3, Dedicated GPS, 4G LTE, RF Pass-Through Antenna, 2MP Front Camera, 8MP Rear Camera, USB 3.2 Type-A x2 + Thunderbolt 4, IP66, 3-Year Durabook Accidental Damage Warranty Coverage
