Explosion Proof Camera Kaixuan KX-EX707PWF2


Explosion proof Camera Kaixuan KX-EX707PWF2 has met all strict explosion proof standards for explosive hazardous environment.

ATEX Rating
Hazardous Area Rating


Trusted Clients

Similar Category:

Explosion Proof Camera Kaixuan KX-EX707PWF2


  • Explosion Proof Camera Kaixuan KX-EX7 07PWF2 is certified to be used in hazardous locations.
  • IR distance:30m.
  • Lens: 4/6mm etc for optional.
  • Support ONVIF, support HIKVISION, DAHUA.
  • DC12V/AC220V for optional.
  • 1* G1/2″.
  • Heater optional.
  • Adopt SONY1/2.7″CMOS Senor CCD ,resolution up to 1920 x 1080 pixel .
  • Adopt TI-DSP CPU. High work efficiency.
  • Fixed lens, easy to monitor remote targets.
  • Support ICR Day/night auto-switch, Color- BW, 24 hours monitoring.
  • High-quality IR lamp, long service life, irradiation distance up to100 meters.
  • Support digital wide dynamic, support 3D-DNR function.
  • Support dual-stream, support mobile phone monitoring.
  • Windows glass surface process by nanotechnology. Well, light transmittance. no halation effect .non-stick oil/dusty.
  • Low power consumption, the fuselage internal air convection heat-dissipation design, can work continuously for a long time.
  • Usual: AC220V/DC12V, other Power modes can be customized.
  • Made of 304 stainless steel material. apply to a strong corrosive environment.
  • Well, design for Explosion-proof, anti-corrosion, waterproof, suitable for an indoor and outdoor environment.

Introducing Explosion Proof Camera Kaixuan-KX-EX707PWF2


II 2G Ex d IIC T6 Gb
II 2D Ex tb IIIC IP68 T80℃ Db
Ingress Protection levelIP66
Cameraimaging sensorSONY 1/2.7″CMOS
minimal illuminationColor 0.1Lux@F1.2, BW0.01 Lux@F1.2;
Day/NightIR-CUT auto-switch
focal distance4MM/6MM ETC
Aperture control Auto
Automatic aperture DC-drive
motion detectingsupport
Compression standardVideo compression standardH.264/H.265/MJPEG
H.264 encoding typeBaseLine Profile / Main Profile
Video compression standard32 Kbps~8Mbps
ImageMaximum resolution1920×1080
Frame rate2 megapixel and following 25 frame(full-time), support 1~25 fps  is adjustable;
Video outputMain Stream:1920×1080,1600×1200,1280×1024,1280×960,1024×768,1280×720;Sub Stream: 640×360,480×270,352×288,320×240,352×192,320×192,288×192,256×192;
Image settingRotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser
NetInterface protocolsONVIF,PSIA,CGI,ISAPI,GB28181
Support protocolsRTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP etc.
audio interfaceoptional
Alarm  interfaceoptional
Laser lampIR distance30M
IR switchIR lamp Auto-open when <0 Lux
Other specificationTemperature range-40℃~60℃
Relative humidity≤ 5%(+25°C)
Atmospheric pressure80kpa~106 kpa
Heater optional
Supply voltageDC12V /AC220V(optional )/POE(Optionnal)
Suitable EnvironmentApply to explosive gas and combustible dust environment
Material304 stainless steel (316, 316L for optional)
Inlet hole specifications G1/2″
Installation methodPTZ,Wall Hanging dyadic , fixed bracket , Pillar base

Suitable application of Explosion-proof Camera Kaixuan KX-EX707PWF2

  • Can be used in extreme situations Such as petroleum, chemical industry, mine, military industry, medicine, oil depot, ships, drilling platform, gas stations, fireworks production, food processing and storage, offshore projects, etc.
