Explosion-Proof Enclosure Kaixuan KX-EX707PWY with Wiper & IR
Explosion Proof Camera Enclosures

Explosion-Proof Enclosure Kaixuan KX-EX707PWY with Wiper & IR

In Stock
SKU: KX-EX707PWY
$810.16
Qty
1

Safety Specifications

Incl. accredited factory seal & certification stamps
ZoneZone 1
Product Description

Kaixuan KX-EX707PWY CCTV Enclosure: ATEX Zone 1 certified. Smart wiper, 304 stainless steel, nanotech-treated glass. Explosion-proof, corrosion-resistant, waterproof. Powered by 220V AC/12V DC. Ideal for challenging conditions. Shop Now.

NOTE:  ENCLOSURE ONLY

Technical Datasheet

Certification & Specification

Country of OriginChina (CN)
ATEX Safety / ZoneZone 1

Product Overview

Explosion-Proof Enclosure Kaixuan KX-EX707PWY with Wiper & IR

Introducing the Kaixuan KX-EX707PWY Explosion-Proof CCTV Camera Enclosure: ATEX Zone 1 certified for hazardous environments. This enclosure features an integrated smart windshield wiper, 304 stainless steel construction for harsh corrosive settings, and nanotechnology-treated glass. It accommodates fixed focus or zoom lens cameras with a 100x300mm inner diameter and 60mm window size. It's explosion-proof, corrosion-resistant, and waterproof to IP66 standards. Powered by a 220V AC/12V DC supply, it's a robust solution for challenging conditions.Kaixuan KX-EX707PWY CCTV Enclosure: ATEX Zone 1 certified. Smart wiper, 304 stainless steel, nanotech-treated glass. Explosion-proof, corrosion-resistant, waterproof. Powered by 220V AC/12V DC. Ideal for challenging conditions.

Features:

  • ATEX Zone 1
  • Ex – Housing
  • Built-in smart windshield wiper
  • 60m IR
  • Inside size: Φ100*300mm
  • Window size: Ф60mm
  • Optional for DC/ AC220 power
  • Can assemble box camera, all-in-one camera
  • 2pcs M25*1.5 output (original G3/4)
  • Original import core, Infrared lighting automatic switching day/ night, 50-100m visibility optional
  • Well light transmittance, no halation effect
  • Windows glass surface process by nanotechnology. Well light transmittance. non-stick oil/dusty /water
  • Low power consumption, the fuselage internal air convection heat dissipation design, can work continuously for a long time
  • Usual: AC220V/DC12V, other Power modes can be customized
  • Made of 304 stainless steel material (316L for optional), apply to a strong corrosive environment
  • Well design for Explosion-proof, anti-corrosion, waterproof, suitable for indoor and outdoor environment
  • IP66

NOTE: Housing only without a camera inside Wiper, IR.

Specifications:

Technical Data
Ex-Level ATEX
II 2G Ex d IIC T6 Gb
II 2D Ex tb IIIC IP68 T80? Db
Ingress Protection  level IP66
Temperature  range -40 to + 60 °C
Relative  humidity 95%+25°C
Atmospheric  pressure? 80kpa to 106 kpa
Infrared distance 60MM
Infrared switch When <0Lux,  Auto open
Wavelength 808nm
Thermostat System Optional
Supply voltage DC12V /AC220V   optional
Suitable environment Apply to explosive gas and  combustible dust environment
Material 304 stainless steel(316L for optional)
inlet interface specifications 2pcs M25*1.5 output(original G3/4)
inside dimension 100mm x 300mm
Windows area 60
Installation  Method PTZ , Wall Hanging dyadic , fixed bracket , Pillarbase
