RamFan EFi150xx – 16″ Explosion Proof Fan

SKU: N/A
(1 customer review)

Certified for ATEX Zone 1, EX II 2 G EX de IIB T6 Gb, this 16-inch explosion-proof fan is marked with the CE hazardous area mark. All of these certifications are also supported by IECEx and INMETRO certifications. the biggest and most powerful blowers for use in potentially dangerous locations Rain-proof witch enclosure (IP55) with integrated duct adapters (both included). A thermally protected cutoff switch and a long-lasting PC/ABS Anti-static housing are also included in the package.

ATEX Rating

IECEx Certified

$3,07270

Price Depends on product option
Make a selection to update price

Clear

Trusted Clients

  • Logo PH66
  • Logo  Exxon
  • Logo Bp
  • Logo Conoco Phillipis
  • Logo Irwing
  • Logo Bayer
  • Logo Tesoro
  • Logo Northen TIer
  • Logo Udelhoven
  • Logo Aloha petroleum
  • Logo Rand
  • Logo Arrow Energy
  • Logo Schlumber
  • Logo Afton
  • Logo Holly frontier
Similar Category:

The Explosion Proof Fan (EPF). It is the largest hazardous site blower with the maximum volume of air movement, the RamFan EFi150xx. Higher speeds, larger volumes, and shorter purge and cooling periods are all possible with EFi150xx. Integrated duct adapters of 40 cm (16 inches) length. Stackable for both storage and operation.

The whole-unit certified electric EFixx Series hazardous site blowers/exhausters are designed for operation in Adverse Atmospheres in compliance with the constraints of the rating. There are many benefits to a full unit certification, including the fact that it avoids suppliers from being tied to the chain of obligation.

Features:

  • ATEX Zone 1
  • IECEx
  • Made in California, USA
  • High-pressure axial blower
  • Durable, PC/ABS Anti-static casing is weatherproof, flame retardant, and chemical resistant
  • 2 Integrated duct adapters
  • IP55 rain switch enclosure

Specifications

ModelEFi150xx (115V)EFi150xx (230V)
Part #EG8200XX Ships as 115VEG8200XX-230 Ships as 230V
IMPA Code591507
Motor1.5 Hp / 1.1 kW
Motor TypeTotally Encapsulated Air Flame Proof
Electric115/230V, 1ø, 50/60 Hz
Amps (Start/Run)80A / 15A40A / 8A
Cable Lengths25’/7.6m, 14AWG/2.5mm2
Plug TypesA.T.X. 100/130VA.T.X. 240V
Operating Temperature-22°F to +104°F / -30°C, to +40°C
Noise90.2 dB @ 3' (1 m)
Weight61 lbs / 28 kg
Dimensions (h/w/d)19 x 18 x16 in / 48 x 46 x 41 cm
Impeller7-Blade

Air Flow

Air Flow4,459 cfm (7,580 m³/hr)
15 ft/4.6 m 1-90° turn3,179 cfm (5,404 m³/hr)

Dimensions

WEIGHT61.73lb
HEIGHT18.9in
WIDTH18.11in
DEPTH16.14in

Certifications:

Resources:

Product Accessories

Make Your Job Easy. Try Our Most Popular Accessories

Euramco ECKO Flex Conductive Duct - 15' ft

$36093

Euramco ECKO Flex Conductive Duct - 15' ft

$62118
