RamFan EFi75xx – 12″ Explosion Proof Fan

SKU: N/A

For ATEX Zone 1, hazardous area rating II 2 G EX de IIB T6 Gb, the EFi75xx – 12″ explosion proof fan is certified. IECEx, INMETRO, and EC Type Examination certifications are also included in the package’s assurances. There are two integrated duct adapters and an IP55 watertight casing. A thermally shielded cutoff switch and a long-lasting PC/ABS Anti-static housing are also included in this kit.

ATEX Rating

IECEx Certified

$2,39583

Price Depends on product option
Make a selection to update price

Clear

Trusted Clients

  • Logo PH66
  • Logo  Exxon
  • Logo Bp
  • Logo Conoco Phillipis
  • Logo Irwing
  • Logo Bayer
  • Logo Tesoro
  • Logo Northen TIer
  • Logo Udelhoven
  • Logo Aloha petroleum
  • Logo Rand
  • Logo Arrow Energy
  • Logo Schlumber
  • Logo Afton
  • Logo Holly frontier
Similar Category:

RamFan EFi75xx – 12″ Explosion Proof Fan with whole-unit certification, EFi75xx is designed for use in Adverse Atmospheres in compliance with the constraints of the rating. The whole-unit certification not only protects the user but also avoids suppliers from being tied to the chain of responsibility.

Features:

  • ATEX Zone 1
  • IECEx
  • Made in California, USA
  • High-pressure axial blower
  • Durable, PC/ABS Anti-static casing is weatherproof, flame retardant, and chemical resistant
  • 2 Integrated duct adapters
  • Starter secured in a flameproof motor enclosure to prevent the risk of ignition when powered on
  • Use pull switch to active ventilator
  • Compact and lightweight
  • Extended power cord
  • Motor part number: EM-F.75-60 XPEX
  • IP55 watertight rain switch enclosure

Specifications

ModelEFi75xx (115V)
EFi75xx (230V)
Part #EB7201XXEB7201XX-230
IMPA Codes591506, 591418,591423591506, 591419,591424
Motor0.75 Hp0.56 kW
Motor TypeTotally Encapsulated Air Flame Proof
Electric115/230V, 50/60Hz, 1ø
Amps (Start/Run)37A /8.8A27A /4.4A
Cable Lengths25'/7.6 m, 14AWG/2.5mm2
Plug TypesA.T.X. 100/130VA.T.X. 240V
Operating Temperature-22°F to +104°F-30°C, to +40°C
Noise89 dB @ 3' (1 m)
Run TimeContinuous
Weight44 lbs20 kg
Dimensions (h/w/d)16 x 15 x 16 in41 x 38 x 41 cm
Duct Adapters2

Air Flow

Air Flow2,500 cfm (4,250 m³/hr)
15 ft/4.6 m 1-90° turn1,664 cfm (2,889 m³/hr)
15 ft/4.6 m duct 2-90⁰1,529 cfm (2,599 m³/hr)

Dimensions

WEIGHT44.09lb
HEIGHT16.14in
WIDTH14.96in
DEPTH16.14in
MOTOR0.33hp

Certifications:

Resources:

Product Accessories

Make Your Job Easy. Try Our Most Popular Accessories

Ramfan-Duct-Adapter-Reducer-main-image

Ramfan Duct Adapter/Reducer (EC0301)

SKU: EC0301

8" Duct Adapter/Reducer for the 12" (EFi & AFi & UB30) Series.

Brand: RamFan

In Stock 10-20 business days

$14673
