Description
Grinsafe Wall-Mounted Explosion-Proof LED Light 60W W25° 3/4″ 480VAC
The Grinsafe FLINT™ GHSM Wall-Mounted Explosion-Proof LED Light is a hazardous-location certified industrial lighting solution designed for Class I Division 1, Class II Division 1, and Zone-rated explosive environments. Featuring a W25° wall-mount bracket with 3/4″ conduit entry and 480VAC industrial voltage compatibility, this rugged LED fixture provides dependable illumination for hazardous areas including oil & gas facilities, offshore platforms, chemical processing plants, and marine environments.
Built with a low-profile copper-free aluminum housing and high-efficiency LED technology, the GHSM series delivers powerful illumination while maintaining excellent durability against vibration, corrosion, moisture, and harsh industrial conditions. Its UL844 certification, marine-rated construction, and IP66/IP67 ingress protection ensure long-term safe operation in explosive gas and combustible dust atmospheres where reliability is critical.
Key Features:
✅ UL844 Certified for Class I Division 1 & 2 hazardous locations
✅ 60W high-efficiency explosion-proof LED fixture
✅ W25° wall-mounted bracket configuration
✅ 347-480VAC industrial voltage compatibility
✅ Up to 9,600 lumens output
✅ Copper-free aluminum corrosion-resistant housing
✅ Shock-resistant and vibration-resistant industrial construction
✅ IP66/IP67 dust-tight and waterproof protection
✅ Marine-rated for offshore and corrosive environments
✅ Long-life LED system rated over 150,000 hours
📦 Package Options:
🔹 Standard Wall Mount Version: GHSM 60W with W25° wall bracket
🔹 347-480VAC Industrial Voltage Model
🔹 Transparent Glass Lens Configuration
🔹 Optional Accessories: Wire guard, visor, safety cable, surge protection
Grinsafe GHSM Wall-Mounted Light Technical Specifications:
| Feature | Details |
|---|---|
| Product Name | Grinsafe GHSM Wall-Mounted Explosion-Proof LED Light |
| Power | 60W |
| Mounting Type | W25° Wall Mount |
| Conduit Entry | 3/4" |
| Input Voltage | 347-480VAC |
| Frequency | 50/60Hz |
| Lumen Output | Up to 9,600 lm |
| Hazardous Rating | Class I Division 1 & 2 |
| Dust Rating | Class II Division 1 & 2 |
| Additional Classification | Class III |
| Zone Rating | Zone 1 / Zone 2 / Zone 21 / Zone 22 |
| Housing Material | Copper-Free Aluminum |
| Lens Material | Tempered Glass |
| IP Rating | IP66/IP67 |
| Operating Temperature | -40°C to +65°C |
| CRI | Ra >70 |
| Beam Angles | 35° / 60° / 90° / 110° / T2 / T3 / T4 |
| Lifespan | L70 > 150,000 Hours |
| Certifications | UL844, UL1598, UL1598A, CSA C22.2 |
| Warranty | 5-Year Limited Warranty |
Certifications & Compliance:
🔗 UL844 – Certified for Class I Division 1 & 2 hazardous locations
🔗 UL1598 – Wet location certified
🔗 UL1598A – Marine and offshore approved
🔗 CSA C22.2 – Canadian hazardous location compliance
🔗 IP66/IP67 – Dust-tight and waterproof enclosure
🔗 Download Datasheet
Applications of Grinsafe GHSM Wall-Mounted Light:
🔹 Oil & Gas Facilities
🔹 Offshore Platforms
🔹 Chemical Plants
🔹 Marine Environments
🔹 Industrial Processing Facilities
What’s in the Box?
📦 1x Grinsafe GHSM 60W Explosion-Proof LED Light
📦 1x W25° Wall Mount Bracket
📦 1x Installation Hardware Kit
📦 1x Documentation Kit
Ordering & Shipping Details
📦 Lead Time: Typically 2–4 Weeks
📍 Shipping Terms: Worldwide / Expedited Options
💳 Payment Options: Credit Card, PayPal, Net 30 Terms
Related Products:
🔗Grinsafe LED Explosion-Proof Ceiling Light 60W with CJB 3/4″ 480VAC
FAQs:
What hazardous area certifications does the GHSM wall-mounted light have?
The fixture is UL844 certified for Class I Division 1 & 2, Class II Division 1 & 2, and Class III hazardous environments.
What does the W25° configuration mean?
W25° refers to the wall-mounted bracket configuration with a 25-degree mounting orientation for optimized directional lighting.
Is this fixture suitable for offshore environments?
Yes. The fixture is UL1598A marine-rated and engineered for corrosive offshore and marine applications.
What voltage range does this model support?
This version supports industrial 347-480VAC electrical systems.
