Intrinsically Safe Ethernet BarriersSKU | BXF3S0101XN040

Intrinsically Safe Ethernet Coupler SOLEXY BXF3S0101XN040

Name: Intrinsically Safe Ethernet Coupler SOLEXY BXF3S0101XN040
Brand: IntrinsicallySafeStore
SKU: BXF3S0101XN040
Price: 829.92 USD
Availability: InStock

In Stock

$829.92

Qty

Safety Specifications

Incl. accredited factory seal & certification stamps

ZoneZone 1

Hazardous AreaClass 1 Division 1

Product Description

The Intrinsically Safe Ethernet Coupler Solexy BXF3S0101XN040 is a certified Zone 1 Class I Div 1 and IECEx ethernet coupler that allows for transmissions of Ethernet into hazardous areas with a standard RJ45 connector. Can be installed with a simple wrench and no potting compounds and made from 300 series stainless that protects the fitting from corrosive environments. It can be hot connected or disconnected without powering down the system. The cable installation and removal can be accomplished without removing power.

Technical Datasheet

Certification & Specification

ATEX Safety / Zone	Zone 1
Hazardous Area Rating	Class 1 Division 1

Product Overview

Intrinsically Safe Ethernet Coupler SOLEXY BXF3S0101XN040

ATEX Zone 1
IECEx
Class I Division 1
No Sealing Fitting Required
Corrosion Resistant
Environmental Protection
Interchangeability
Industrial M12 “D” connection
Cable length: 40" 1 mt CAT5e
AISI303 stainless steel
Thread connection: 3/4" NPT
Suitable for hazardous area
Housing Connector: Shielded M12 Female "D" coded
Housing Material: 300 SST(approximate weight 0,38kg (0.83lb))
Protection: 3.6 V
Maximum Fault Voltage: RMS 250 V
Ambient Temperature range: -40°C (-40°) to +85°C (+185°F) (T4) and -40°C(-40°F) to +60°C (+140°F) (T5)

Introducing the Intrinsically Safe Ethernet Coupler Solexy BXF3S0101XN040 is an ethernet coupler certified Atex Zone 1, Class 1 Div 1 and IECEx ratings that allows for transmissions of Ethernet into hazardous areas with a standard RJ45 connector. With the Solexy Ethernet coupler, it’s possible to connect any standard ethernet devices located in a classified or safe area. This device is certified for installation in classified areas. Designed to be used with any USA&Canada, ATEX or IECEx listed explosion proof housing without the need of a seal fitting, taking up no internal space.

Solexy’s patented (7,057,105) Explosion-Proof / Intrinsically Safe Ethernet Coupler allows for transmissions of Ethernet into hazardous areas with a standard RJ45 connector. A BXF and/or BAF coupler is required on each end of a cable installation for full protection of both the RX and TX lines.
