Intrinsically Safe 10-Inch Variable Speed Exhaust Fan with Shutters – 690 CFM Direct Drive (Model: SD10-ECV)

“Our intrinsically safe standard fans uphold a legacy of quality in design, materials, and construction. Each fan is crafted to deliver efficiency and affordability. With the option of EC motors, our fans offer up to 70% energy savings.

To determine the appropriate fan for your needs, use this formula:

Cubic feet of room / Minutes per air change = Required CFM Capacity

For example, for a general office requiring an air change every ten minutes, with dimensions of 100’ x 40’ x 10’ totaling 40,000 cubic feet, you would need a fan with a capacity of 4000 CFM. Refer to our chart to select a fan rated at 4000 CFM at 1/8” S.P. (Static Pressure).”

Features

• SD10 model features 2 louvers
• Available in sizes ranging from 8” to 36″
• Equipped with a high-efficiency totally enclosed ECsmart motor
• Features a rugged steel welded box housing with a durable powder coat finish
• Includes an OSHA guard on the intake side of the fan
• 8″ to 24″ models now upgraded with tie bar shutters and magnets for quieter operation and superior seal
• All fans are shipped fully assembled for immediate use
• Fans with variable speed motors offer the flexibility to operate as either an energy-efficient single-speed fan or in variable operation with the appropriate controller


  Specifications

  • Model No.: SD10-ECV
  • Voltage: 115 / 208-280
  • Warehouse: New York
  • Type: Exhaust
  • Amps: 2.8 / 1.7-1.3
  • Blade Material: Steel
  • Blade Size (Inches): 10
  • Number of Blades: 3
  • CFM High: 690
  • Construction: Steel
  • Decibels (dBA): 56 @ 5ft
  • Dimensions (inches): Width: 15.25″, Depth: 13.5″, Height: 15.25″
  • Hertz: 60
  • Drive Type: Direct
  • Horsepower: 1/4
  • Limited Warranty: 1 Year Limited
  • Motor Type: TE
  • RPM High: 1800
  • Phase: 1
  • Speed(s): Variable
  • Weight (lbs.): 22


    Datasheet:

  Intrinsically Safe 10-Inch Exhaust Fan SD10-ECV Datasheet

  Instructional Manual:

  Intrinsically Safe 10-Inch Exhaust Fan SD10-ECV Instructional Manual
