Features:
- Enclosure in Copper-free Aluminium Alloy, powder-coated surface, yellow (RAL1021).
- Built-in electronic ballast, wide voltage input, rapid starting, stable performance, power factor≥0.95.
- Built-in LED driver, wide voltage input, CC-CV (constant current – constant voltage) output, power factor≥0.95.
- End of lamp life (EOL) rectification effect protection.
Specifications:
| Global (IECEx) | IECEx CQM 12.0042X |
| Gas and dust | Ex d IIC T6 Gb; |
| Ex t IIIC T80℃ Db IP66 | |
| Europe (ATEX) | LCIE 09 ATEX 3046 |
| Gas | II 2 G Ex d IIC T6 Gb |
| II 2 G Ex tb IIIC T80℃ Gb IP66 | |
| Certificates | IECEx; ATEX; CU-TR |
| Conformity to standards | EN; IEC |
| Degree of protection | IP66/IP67 |
| Ambient temperature | -20℃~+55℃ |
Data
| Material | Copper-free Aluminium Alloy, powder coated surface, yellow (RAL1021) Toughened glass, stands 4J impact |
| Weight | 5.6~19.2kg |
| Dimensions | 1878x210x250mm |
| Lamp specification | T8 tube |
| Lamp power (W) | 18W（18W/58W） x 1；18W（18W/58W） x 2 |
| Rated voltage | 100~300V AC 50/60Hz |
| Rated luminous flux | 1300~10000lm |
| Terminal | 3 x 1.5~4mm2 (L+N+PE) |
| Cable entries | 4 |
| Cable gland (optional) | DQM-II (Ex d) or DQM-III (Ex d) |
