Intrinsically Safe James Industry V Series Explosion Proof Exit Sign

• Integrated Junction Box with Emergency Backup
• IP66 Ingress Protection Rating
• Low Energy Consumption Options (1W/2W/5W)
• 3-Hour Emergency Operation Capability
• Stainless-Steel Exposed Fasteners: High Corrosion Resistance
• Alternate Exit Legend and Multiple Language Options Available

Two Options of Function:

• Model 1: EXIT sign remains on with or without mains electricity.
• Model 2: EXIT sign does not light up when there is mains electricity, but only lights up when there is a power outage.

James Industry V Series Explosion Proof Exit Sign

Explanation of Indicator Light:

Reset Instructions:

If three or two indicator lights stay on during initial power on: Press the switch "ON" for 5 to 6 seconds -> OFF -> ON.

Indicator Lights:

• RED:
  • Fast charging for 2 hours.
  • Charging indicator for 20% - 80% battery capacity.
• GREEN:
  • Trickle charging.
  • Charging indicator for 80% - 100% battery capacity.
  • Illuminates when disconnecting the battery.
• RED and GREEN:
  • Alternating flashes indicate 80% battery capacity for 5 minutes.
• YELLOW:
  • Indicates discharge below 20%.
  • If the yellow light is on in any state, it signifies a product malfunction.

Description of Switch:

• Press the switch "ON" once: The EXIT sign and indicator light will flash once with a 10-second ON/OFF interval.
• To turn off the product: Disconnect mains electricity, then long press and hold the switch for 3 to 5 seconds. To activate the EXIT sign again, reconnect mains electricity.
• Monthly Inspection: Automatically conducted every 30 or 31 days. The EXIT sign and indicator light will flash once.
• Annual Inspection: Automatically performed once a year. The EXIT sign and indicator light will flash twice.

James Industry V Series Explosion Proof Exit Sign

Specifications:

James Industry V Series Explosion Proof Exit Sign

Resources

• James Industry V Series Explosion Proof Edge Lit LED Exit Sign Certification & Datasheet
