Intrinsically Safe KX-EX09CBD8-NVR-POE

Intrinsically Safe KX-EX09CBD8-NVR-POE

The KX-EX09CBD8-NVR-POE is a robust, ATEX-certified stainless steel NVR designed for hazardous environments. This 8-channel NVR features Power over Ethernet (PoE) support, advanced video decoding, and simultaneous HDMI/VGA full HD outputs. Built to withstand harsh conditions, it offers exceptional safety and performance for industrial monitoring applications.

Key Features:

• ATEX Certification: Designed for hazardous areas, certified for gas (II 2G Ex d IIC T6 Gb) and dust environments (II 2D Ex tb IIIC IP68 T80°C Db).
• Build Quality: Stainless steel casing with IP66 ingress protection for durability in harsh industrial conditions.
• Video Performance:
  • 8 PoE Channels: Directly supports 8 cameras with PoE power and connectivity.
  • Extended Camera Support: Manages up to 10 IP cameras over the network (non-real-time).
  • Video Compression: H.265AI / H.265+ (compatible with H.265/H.264).
  • Display and Playback Quality: Resolutions up to 4K, 5M, 4M, 3M, and 1080P.
• Power over Ethernet (PoE): 8 PoE ports with a maximum power supply distance of 100 meters.
• Storage: Supports 1 SATA HDD (up to 14TB) with additional options for network and USB backups.
• Output Interface: Simultaneous HDMI and VGA outputs support full HD quality.
• Connectivity: Offers comprehensive network services, including DHCP, FTP, DNS, DDNS, NTP, UPNP, EMAIL, 3G, WIFI, and IP search. Fully ONVIF-compliant for third-party IP cameras.
• Ease of Use: Embedded Linux OS with a 16-bit true color graphic menu and mouse operation.

Applications:

• Oil and Gas Facilities
• Chemical Processing Plants
• Industrial Manufacturing Sites
• Mining Operations
• Hazardous Zones Requiring ATEX-Certified Monitoring Solutions



Specifications:

Feature	Details
Certification	ATEX (II 2G Ex d IIC T6 Gb, II 2D Ex tb IIIC IP68 T80°C Db), IP66
Video Input	10 channels, 4K (not real-time)
Compression	H.265AI/H.265+ (compatible with H.265/H.264)
Playback Quality	4K/5M/4M/3M/1080P
POE Ports	8 ports (up to 100m power supply distance)
Storage	1 SATA HDD (up to 14TB)
Network Interface	1 RJ45 10M/100M Adaptive Ethernet Port
Power Supply	48V/1.5A

Package Includes:

• 1 x KX-EX09CBD8-NVR-POE Unit
• 1 x Power Supply (48V 1.5A)
• 1 x User Manual
• Mounting Accessories

Benefits:

• Hazardous Environment Certified: Ensures safety and compliance for explosive gas and dust areas.
• High Performance: Supports high-resolution video feeds for critical monitoring.
• Simplified Installation: Integrated PoE ports reduce the need for separate power sources.
• Reliable Storage: Up to 14TB HDD storage for extensive recording needs.
• Seamless Compatibility: ONVIF compliance for third-party IP cameras.

Resources and Certifications:

• Certifications: ATEX (Gas and Dust) – II 2G Ex d IIC T6 Gb / II 2D Ex tb IIIC IP68 T80°C Db
• User Manual and Installation Guide: Available upon request or on Kaixuan’s website.

Accessories:

• Additional SATA HDD for storage expansion
• Rack-mounting kit
• Compatible ATEX-certified IP cameras

Extra Information:

• Warranty: Standard 2-year manufacturer’s warranty.
