Hazardous Area Monitor – AcuBrite ATEX C1D2

The Hazardous Area Monitor – AcuBrite ATEX C1D2 series is a line of rugged, Canadian-engineered industrial monitors built for demanding environments. Featuring sunlight-readable 1000 NITS LED displays and multi-touch capacitive screens, AcuBrite ensures superior visibility and performance even under extreme temperatures. Access to clear, reliable visual data is critical for safety and operational efficiency in hazardous locations, and this monitor is engineered to provide just that without compromise.

With certifications including Class I, Division 2 and ATEX, the AcuBrite monitors are trusted for hazardous areas across oil & gas, chemical, and mining sectors. Designed with IP65 front protection, durable aluminum alloy housing, and versatile VESA/panel mounting options, they deliver reliability where failure is not an option.

Key Features:

• ✅ Certified for Hazardous Areas: Certified for Class I, Division 2, Groups A, B, C, D, T4 and ATEX II 3 G Ex nA IIC T4 Gc. Refer to the datasheet for full certification details.
• ✅ Sunlight Readable Display: The LED-backlit LCD with 1000 NITS high brightness provides crystal-clear visibility even in direct sunlight or bright ambient light conditions.
• ✅ Responsive Multi-Touch Screen: Features a 10-point capacitive multi-touch screen for intuitive operation, with an optional resistive touch model for legacy applications (4:3 ratio only).
• ✅ Washable Front Panel: The IP65-rated front panel is protected against dust ingress and low-pressure water jets, making it suitable for clean-down procedures in industrial settings.
• ✅ Extreme Temperature Operation: A wide operating temperature range of -40°C to +60°C ensures reliable performance in the most severe climates, from freezing outdoor conditions to hot industrial plants.
• ✅ Versatile Sizing: Available in multiple sizes from 10" to 32" with both 16:9 widescreen and 4:3 standard aspect ratios to fit various installation requirements.
• ✅ Multiple Connectivity Options: Equipped with HDMI, VGA, USB-B (for touch functionality), and an audio jack, plus built-in speakers for comprehensive interfacing.
• ✅ Rugged Construction: Built with a durable aluminum alloy housing to withstand shock and vibration typical in industrial environments.
• ✅ Flexible Mounting: Supports both panel mount and standard VESA mounting for easy integration into control panels, walls, or machine mounts.
• ✅ Globally Recognized Certifications: Meets CSA, UL, FCC, and UKCA standards for safety and quality assurance.
• ✅ Comprehensive Warranty: Backed by a 3-year bumper-to-bumper warranty for peace of mind and long-term reliability.

Package Options:

• 📦 AcuBrite 10" – 16:9 | 4:3
• 📦 AcuBrite 12" – 16:9 | 4:3
• 📦 AcuBrite 13" – 16:9
• 📦 AcuBrite 15" – 16:9 | 4:3
• 📦 AcuBrite 17" – 16:9 | 4:3
• 📦 AcuBrite 18.5"/19" – 16:9 | 4:3
• 📦 AcuBrite 22" – 16:9
• 📦 AcuBrite 24" – 16:9
• 📦 AcuBrite 32" – 16:9
• 📦 AcuBrite 15" – 24V DC Power Input

Specifications:

Feature	Details
Display Sizes	10", 12", 13", 15", 17", 18.5/19", 22", 24", 32"
Aspect Ratios	16:9 or 4:3 (depending on model)
Brightness	1000 NITS LED backlit
Touchscreen	Capacitive multi-touch (10-point); resistive optional on 4:3
Resolution	Up to 1920 x 1080
Operating Temp	-40°C to +60°C (-40°F to +140°F)
Power Input	100–240V AC
Inputs	HDMI, VGA, USB-B (touch), 3.5mm Audio
Ingress Protection	IP65 front panel
Certifications	C1D2 (Groups A-D, T4), ATEX Zone 2 (Gas), CSA, UL, FCC, UKCA
Construction	Aluminum alloy, panel & VESA mounting
Weight Range	4.1 lbs (10") – 24.3 lbs (32")
Warranty	3-year bumper-to-bumper

What's in the Box?

• 📦 1x AcuBrite Industrial Monitor (size selected)
• 📦 1x Power Supply (110–240V AC)
• 📦 1x USB Touch Cable
• 📦 1x HDMI Cable
• 📦 1x Documentation Kit

Certifications & Compliance:

• 🔗 ATEX – Certified for explosive atmospheres.
• 🔗 C1D2 – North American hazardous area compliance.
• 🔗 CSA, UL, FCC, UKCA – Meets key international safety and regulatory approvals.
• 🔗 IP65 – Dustproof and water-resistant front panel for industrial wash-downs.
• 🔗 MIL-STD-810H shock tested, ensuring durability against physical impacts.
• 🔗 3-year bumper-to-bumper warranty, guaranteeing product quality and support.
• 🔗 Download Datasheet for complete technical details.

Applications:

• 🔹 Oil & Gas: Ideal for Human-Machine Interface (HMI) applications on drilling rigs, pipeline control rooms, and offshore platforms where flammable gases are present.
• 🔹 Chemical Plants: Used for process control monitoring and data visualization in environments with volatile chemical vapors.
• 🔹 Industrial Manufacturing: Suitable for paint booths, solvent handling areas, and other manufacturing zones requiring Class I, Division 2 certified equipment.
• 🔹 Pharmaceuticals: Can be deployed in cleanrooms and processing areas where flammable cleaning agents or solvents create a hazardous atmosphere.

Ordering & Shipping Details

• 📦 Lead Time: 3–4 weeks (depending on configuration)
• 📍 Shipping Terms: Worldwide / Expedited Options Available
• 💳 Payment Options: Credit Card, PayPal, Net 30 Terms for qualified customers

Our specialists are ready to help you select the right configuration for your specific application. For custom orders, volume pricing, or to confirm compliance requirements, please request a quote today. We ensure your equipment is certified, tested, and ready for deployment in your hazardous environment.

Related Products:

• 🔗 Intrinsically Safe Keyboards: Pair your monitor with a rugged, certified keyboard and pointing device for a complete HMI solution. CHECK OUT NOW!
• 🔗 ATEX Enclosures: Protect your connections and power supplies with our range of certified enclosures for hazardous areas. CHECK OUT NOW!

FAQs:

What sizes are available?
From 10" up to 32", with options for 16:9 and 4:3 aspect ratios to fit a wide range of industrial panel and VESA mount applications.

Are these monitors sunlight-readable?
Yes, they feature a high-brightness 1000 NITS LED display, specifically designed for clear visibility in direct sunlight and other bright outdoor or indoor environments.

Do they work in hazardous areas?
Yes, they are certified for Class I, Division 2 and ATEX Zone 2 hazardous locations with flammable gases or vapors. Please consult the product datasheet for full certification details, including gas groups and temperature ratings, to ensure suitability for your specific application.

What is the warranty?
AcuBrite comes with a comprehensive 3-year bumper-to-bumper warranty that covers all parts and labor, ensuring long-term operational reliability.

Can the monitor withstand corrosive environments?
The rugged aluminum alloy housing provides excellent durability. For environments with specific corrosive agents (e.g., saltwater spray or chemicals), we recommend discussing your application with our specialists to ensure optimal material compatibility. We can advise on additional protective measures if needed.

What are the power input requirements?
The standard model includes a 110–240V AC power supply. A dedicated 24V DC power input option is also available for certain models, like the 15-inch version, to integrate directly with industrial power systems. Please specify your power requirements when requesting a quote.
