Intrinsically Safe Warom Explosion-proof Junction Boxes BHD91

SKU: BHD91

The Intrinsically Safe Warom Explosion-proof Junction Boxes BHD91 has explosion protection to IEC, NEC, EN, UL, CSA and can be used in Zone 1,2,21,22,Class I,Division 1,Groups A, B, C, D.

$5250

Out of stock

Trusted Clients

  • Logo PH66
  • Logo  Exxon
  • Logo Bp
  • Logo Conoco Phillipis
  • Logo Irwing
  • Logo Bayer
  • Logo Tesoro
  • Logo Northen TIer
  • Logo Udelhoven
  • Logo Aloha petroleum
  • Logo Rand
  • Logo Arrow Energy
  • Logo Schlumber
  • Logo Afton
  • Logo Holly frontier
Similar Category:

Intrinsically Safe Warom Explosion-proof Junction Boxes BHD91

◆ Four types: A,B,C,D

◆ Copper-free Aluminium Alloy enclosure, powder-coated surface.

Specifications

Global (IECEx)IECEx CQM 15.0061X
Gas and dustEx db IIC T6 Gb
Ex tb IIIC T80℃ Db IP66
Europe (ATEX)CNEX 16 ATEX 0006
Gas and dust II 2 G Ex db IIC T6 Gb
  II 2 D Ex tb IIIC T80℃ Db IP66
CertificatesIECEx; ATEX; CU-TR;UL
Conformity to standardsEN;IEC
Degree of protectionIP66/IP67(Optional)

Data

MaterialCopper-free Aluminium Alloy, powder coated surface
Weight1.2kg
Dimensions146mm×163mm×100mm
Enclosure colourWindow grey (RAL7040)
Exposed fastenerStainless steel
Rated voltageMax. 500V AC
Rated current24A, 32A, 41A
Internal&external earthingM4/M5
Cable gland(optional)DQM-II(Ex d), DQM-III(Ex d)

Intrinsically Safe Warom Explosion-proof Junction Boxes BHD91 Certifications:

Intrinsically Safe Warom Explosion-proof Junction Boxes BHD91 IECEX Certification

Intrinsically Safe Warom Explosion-proof Junction Boxes BHD91 Other Resources:

Intrinsically Safe Warom Explosion-proof Junction Boxes BHD91 Brochure
