Pixavi Intrinsically Safe Scan Module
The Pixavi Intrinsically Safe Scan Module enhances the functionality of the Pixavi Phone by adding a powerful, integrated Zebra scan engine for reliable 1D and 2D barcode scanning. Designed to withstand the toughest environments, this module is ideal for use in hazardous areas such as oil and gas facilities, chemical plants, and other industries requiring explosion-proof equipment. With a sleek, lightweight design and easy snap-on installation, the scan module allows workers to streamline processes and improve productivity without compromising safety.
Features
- Intrinsically Safe Design: Certified for use in hazardous environments, meeting ATEX, IECEx, and NEC standards.
- Zebra Scan Engine: High-performance scanning with a range of up to 14 meters, capable of reading a variety of 1D and 2D barcodes.
- Wide Compatibility: Compatible with the Pixavi Phone running Android 11 or later.
- Dust and Waterproof: IP68-rated enclosure ensures durability and reliable operation in challenging conditions.
- Lightweight and Compact: Weighs approximately 130 grams, adding minimal bulk to the Pixavi Phone.
- LED Indicator: Visual confirmation with a green LED when no target is detected and a red LED when a barcode is scanned.
Benefits
- Improved Efficiency: Streamlines data capture processes, reducing errors and improving workflow in hazardous environments.
- Enhanced Safety: Certified for use in explosive atmospheres, providing a safe and reliable solution for data collection.
- Versatile Scanning: Capable of reading a wide range of barcode types from various distances, making it suitable for diverse applications.
Applications
- Hazardous Locations: Ideal for use in Zone 1/21, Class I Division 1/Zone 0 areas, and other classified environments.
- Industrial Automation: Suitable for inventory management, asset tracking, and other industrial applications requiring precise barcode scanning.
- Logistics and Warehousing: Facilitates efficient barcode scanning for tracking and managing goods in hazardous areas.
Certifications and Standards
- ATEX Certification: II 2G Ex ib op is IIC T4 Gb, II 2D Ex ib op is IIIC T135°C Db IP68.
- IECEx Certification: Ex ib op is IIC T4 Gb, Ex ib op is IIIC T135°C Db IP68.
- NEC Certification: Class I, Division 1, Groups A, B, C, and D; Class I, Zone 0, AEx ia op is IIC T4 Ga.
Technical Specifications
- Operating Temperature: -20°C to +60°C (-4°F to +140°F).
- Charging Temperature: 0°C to +40°C (+32°F to +113°F).
- Protection Class: IP68, ensuring dust and waterproof performance.
- Power Supply: 3.8 V, 3200 mAh Lithium-ion battery.
- Barcode Scanner:
- Model: SE55 from Zebra.
- Scanning Range: Up to 14 meters, depending on barcode type and quality.
- Supported Symbologies: Includes 1D and 2D codes like Code 128, QR Code, Data Matrix, PDF417, and more.
- Decoder Board: Controlled via the PL5000 decoder board.
