Spectrum D201-X-Q6078-BD Explosion-Proof 4K PTZ Camera
Spectrum Explosion-Proof Ultra-HD 4K PTZ Camera
Casing
- A = Aluminum casing powder coated red
- S = Stainless Steel
| Technical Data | |
| Camera | D201-X-Q6078-BD |
| Image sensor | 1/2.5” progressive scan RGB CMOS |
| Lens | 4.4–88.4 mm, F2.0-3.8 Horizontal field of view: 68.3°-4.2° Vertical field of view: 42.1°-2.34° Autofocus, P-iris control |
| Day and night | Automatically removable infrared-cut filter |
| Minimum illumination | Color: 0.2 lux at 30 IRE, F2.0 |
| B/W: 0.002 lux at 30 IRE, F2.0 | |
| Shutter speed | 1/10000 s to 1 s |
| Pan/Tilt/Zoom | Pan: 360° endless, 0.05°–450°/s Tilt: 220°, 0.05°–450°/s Zoom: 20x optical, 12x digital, total 240x zoom E-flip, 256 preset positions, tour recording (max 10, max duration 16 minutes each), guard tour (max 100), control queue, on-screen directional indicator, orientation aid PTZ, set new pan 0°, adjustable zoom speed, focus recall |
| Sensor | AXIS Q6078-E |
| System on chip (SoC) | |
| Model | ARTPEC-7 |
| Memory | 2 GB RAM, 512 MB Flash |
| Compute Capabilities | Machine learning processing unit (MLPU) |
| Video | |
| Video compression | H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High Profiles H.265 (MPEG-H Part 2/HEVC) Main Profile Motion JPEG |
| Resolution | 3840x2160 4K 2160p to 320x180 |
| Frame rate | Up to 25/30 fps (50/60 Hz) in 4K Up to 50/60 fps (50/60 Hz) in all other resolutions |
| Video streaming | Multiple, individually configurable streams in H.264, H.265 and Motion JPEG Axis Zipstream technology in H.264 and H.265 Controllable frame rate and bandwidth VBR/ABR/MBR H.264/H.265 |
| Image settings | Manual shutter time, compression, color, brightness, sharpness, WDR – dynamic contrast, white balance, exposure control, exposure zones, fine tuning of behavior at low light, rotation: 0°, 180°, text and image overlay, polygon privacy masks, electronic image stabilization (EIS), freeze on PTZ, defog, backlight compensation, scene profiles |
| Network | |
| Security | Password protection, IP address filtering, HTTPSa encryption, IEEE 802.1x (EAP-TLS)a network access control, digest authentication, user access log, centralized certificate management, brute force delay protection, signed firmware, secure boot, Axis Edge Vault, Axis device ID, secure keystore (CC EAL4 certified), TPM (FIPS 140-2 certified) |
| Supported protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTP/2, HTTPSa, TLSa, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SOCKS, SSH, NTCIP, LLDP, CDP, MQTT v3.1.1, Syslog, Link-Local address (ZeroConf) |
| System integration | |
| Application programming interface | Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at axis.com One-Click Cloud Connection ONVIF® Profile G, ONVIF® Profile S and ONVIF® Profile T, specification at onvif.org |
| Event conditions | Device status: above operating temperature, above or below operating temperature, below operating temperature, fan failure, IP address removed, network lost, new IP address, shock detected, storage failure, system ready, within operating temperature Edge storage: recording ongoing, storage disruption I/O: manual trigger, virtual input MQTT subscribe PTZ: PTZ malfunctioning, PTZ movement, PTZ preset position reached, PTZ ready Scheduled and recurring: scheduled event Video: live stream open |
| Event actions | Day/night mode, overlay text, video recording to edge storage, pre- and post-alarm video buffering, send SNMP trap PTZ: PTZ preset, start/stop guard tour File upload via FTP, SFTP, HTTP, HTTPS network share and email MQTT publish Notification via email, HTTP, HTTPS and TCP |
| Data streaming | Event data |
| Built-in installation aids | Pixel counter, leveling guide |
| Analytics | |
| Applications | Included |
| AXIS Object Analytics, AXIS Video Motion | |
| Detection, AXIS Motion Guard, AXIS Fence Guard, AXIS Loitering Guard, autotracking 2, active gatekeeper, AXIS OSDI Zones, Orientation Aid PTZ |
|
| Support for AXIS Camera Application Platform enabling installation of third-party applications, see axis.com/acap |
|
| Axis Object Analytics | Object classes: humans, vehicles Trigger conditions: line crossing, object in area Up to 10 scenarios Metadata visualized with color-coded bounding boxes Polygon include/exclude areas Perspective configuration ONVIF Motion Alarm event |
| General | |
| Casing (x) | A = Aluminum |
| S = Stainless Steel | |
| Weight | A = 32 lbs (14 kg) |
| S = 68 lbs (28 kg) | |
| Dimensions | Height: 15.9 in (404 mm) ø 8.6 in (218 mm) |
| Power | 44 - 57 Vdc 60W |
| Storage Conditions | -40 °C to 65 °C Humidity 5–95% RH (non-condensing) |
| Operating Conditions | -20°C to +50°C Humidity 10-100% RH (condensing) |
| Warranty | 5-year limited warranty, see www. spectrumcamera.com/warranty |
| Approvals | Hazardous Area FM3600, FM3615, ANSI/ISA/EN/IEC/CAN/ CSA-C22.2 60079-0, ANSI/UL/EN/IEC/CAN/ CSA-C22.2 60079-1, ANSI/UL/IEN/EC/CAN/ CSA-C22.2 60079-31 |
| EMC EN 55032 Class A, EN 50121-4, IEC 62236-4, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, RCM AS/NZS CISPR 32 Class A, KC KN32 Class A, KC KN35 | |
| Safety IEC/EN/UL 60950-22, IEC/EN/UL 62368-1, IS 13252 | |
| Environment IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC60068-2-78, IEC/EN 60529 IP66/IP67, IEC/EN 62262 IK10, NEMA 250 Type 4X, NEMA TS 2 (2.2.7-2.2.9) | |
| NIST SP500-267 | |
| Explosion-proof Certifications | USA (Divisions): Class I Division 1 Groups B,C,D T6, type 4X, IP66/67 Class II/III, Division 1, Groups E,F,G T6 Ta = -20°C to +50°C |
| Certificate: FM17US0156X | |
| USA and Canada (Zones): Class I, Zone 1, AEx/Ex db IIB+H2 T6 Gb Ta -20°C to +50°C, Type 4X, IP66/67 Zone 21, AEx/Ex tb IIIC T85 °C Db Ta = -20°C to +50°C, Type 4X, IP66/67 | |
| Certificate: FM17US0156X and FM18CA0103X | |
| ATEX: II 2 G Ex db IIB+H2 T6 Gb Ta = -20°C to +50°C, IP66/67 | |
| II 2 D Ex tb IIIC T85 °C Db Ta = -20°C to +50°C, IP66/67 | |
| Certificate: FM18ATEX0057X | |
| IECEx: Ex db IIB+H2 T6 Gb Ta = -20°C to +50°C, IP66/67 | |
| Ex tb IIIC T85 °C Db Ta = -20°C to +50°C, IP66/67 | |
| Certificate: FMG 18.0020X | |
| INMETRO: Ex db IIB+H2 T6 Gb Ta = -20°C to +50°C, IP66/67 | |
| Ex tb IIIC Db T85 °C Ta = -20°C to +50°C, IP66/67 | |
| Certificate number: NCC 20.0083 X | |
| Video Management Software | AXIS Companion, AXIS Camera Station, video management software from Axis Application Development Partners available at axis.com/ vms |
| Languages (Camera) | English, German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese, Traditional Chinese |
