Tomar D1xL1F 15 Watt PA Loudspeaker-Intrinsically Safe
Tomar D1xL1F 15 Watt PA Loudspeaker-Intrinsically Safe, stands as a robust 15W PA loudspeaker featuring a re-entrant flare horn, designed for versatility in hazardous environments. Enclosed in a corrosion-proof aluminum enclosure with a high Sound Pressure Level, rated at type 4/4X and IP66 marine grade, this loudspeaker is ideal for Class I & II Division 1 and Zone 1 & 20 explosion-proof applications.
Constructed with a high-impact, fire-retardant ABS re-entrant flare horn, field replacement is made seamless with a standard 1 3/8″ -18 male thread coupling for the driver. Offering triple cable entries and spacious termination areas, installation is flexible and maintenance-friendly.
Notably, the termination chamber and cover feature a threaded flameproof joint, simplifying both initial installation and routine maintenance procedures. The Tomar D1xL1F ensures a reliable and adaptable solution for intrinsically safe sound signaling in challenging environments.
Features:
- High Output: Delivers powerful sound output for effective signaling.
- Compact Form Factor: Space-efficient design for versatile installation options.
- Multiple Transformer Tapping: Allows flexibility in adjusting the loudspeaker’s performance to suit different requirements.
- Field Replaceable Flare Component: Simplifies maintenance by enabling the replacement of the flare component in the field.
- Robust Corrosion-Proof Aluminum Enclosure: Ensures durability and resilience in challenging environments.
- Ratchet Adjustable Stainless Steel Bracket: Provides a sturdy and adjustable mounting solution.
- Stainless Steel Fixings: Enhances the loudspeaker’s resistance to corrosion and environmental wear.
- Triple Cable Entries: Facilitates flexible cable routing for easy installation.
- Duplicate Cable Terminations: Adds redundancy to cable connections for increased reliability.
- Threaded Cover Joint for Fast Installation: Streamlines both initial installation and routine maintenance procedures with a threaded cover joint.
Tomar D1xL1F 15 Watt PA Loudspeaker
Approvals
- UL File ref: E230764
- UL1203 Ed. 5
- CAN/CSA C22.2 No. 25-1966
- CSA C22.2 No. 30-M1986
- CSA C22.2 No. 205-12
- UL1480 Ed. 6
Commercial and professional use
Coding
- A1: Gas version- NEC / CEC:
• Class I Div 1 ABCD T6 Ta -40°C to +70°C
• Class I Div 2 ABCD T6 Ta -40°C to +70°C
• Class I Zone 1, 2 IIC T6 Ta -40°C to +70°C - D1: Dust version – NEC / CEC:
• Class II Div 1 FG T6 Ta -40°C to +70°C
• Class II Div 2 FG T6 Ta -40°C to +70°C
• Class III Div 1 & 2
• Zone 20, 21, 22 IIIB Ta -40°C to +70°C
• Protection concept: Ex d / AEx d - Ratings:
- A1: Gas version – NEC / CEC:
Class I Div. 1 ABCD T6 Ta -40°C to +70°C
Class I Div. 2 ABCD T6 Ta -40°C to +70°C
Class I Zone 1 IIC T6 Ta -40°C to +70°C - D1: Dust version – NEC / CEC:
Class II Div. 1 FG T6 Ta -40°C to +70°C
Class II Div. 2 FG T6 Ta -40°C to +70°C
Class III Div. 1&2
Zone 20 IIIB Ta -40°C to +70°C
Tomar D1xL1F 15 Watt PA Loudspeaker
Specifications:
| Technical Data | ||
| Item | Description | |
| SPL (Gas version) | 102dB +/-3dB @ 1W @ 1m (Pink) | |
| 113dB +/-3dB @ 15W @ 1m (Rated) | ||
| SPL (Dust version) | 83dB +/-3dB @ 1W @ 1m (Pink) | |
| 95dB +/-3dB @ 15W @ 1m (Rated) | ||
| Rated power | 15 Watts RMS | |
| 70v line tapping | 15W/7.5W/3W/1W (z=336.67 Ohms/653.33 Ohms/1.6k Ohms/4.9k Ohms) | |
| Low impedance | 8 Ohm or 16 Ohm | |
| Directivity Index | 6.2 @ 1 kHz & 16.0 @ 4 kHz [dB on-axis] | |
| Frequency range | 400Hz to 8000 Hz | |
| DC Line monitoring | 2.2µF Capacitor (Transformer | |
| 470µF Capacitor (Low impedance) | ||
| Ingress protection | EN60529: IP66 UL50E / NEMA250: 4 / 4X / 3R / 13 | |
| Enclosure material | Marine grade aluminum LM6- copper free Chromate & powder coated – corrosion proof | |
| Color | Red (RAL3000), Grey (RAL7038) | |
| Cable entries | 1 x 1/2"NPT & 2 x M20 x 1.5mm | |
| 1 x 1/2"NPT & 2 x 1/2"NPT | ||
| 1 x 1/2"NPT & 2 x 3/4"NPT | ||
| Terminals | 0.5 - 2.5mm² (20-14 AWG) | |
| Grounding stud | M5 | |
| Operating temp | -40° to +70°C [-40° to +158°F] | |
| Storage temp | -50° to +70°C [-58° to +158°F] | |
| Relative humidity | 90% at 20°C [68°F] | |
| Weight | 70V line: 4.3kg/9.5Ibs | |
| Low imp. | 4.0kg/8.7Ibs | |
| Ordering Information | ||
| Model | Line Transformer | Rated Power |
| D1xL1F | 70 VRMS | 15 Watts RMS |
| 1 x ½” NPT & 2 x M20 x 1.5 mm; brass stopping plug. 304 (A2) Stainless steel mounting bracket |
