Explosion Proof Fan Atlantic Blowers ABAF-8-110E

Out of StockSKU: ABAF-8-110E

$0.00

This product is currently unavailable. Our team can help you find a suitable alternative or advise on lead times.

Safety Specifications

Incl. accredited factory seal & certification stamps

Hazardous Area RatingClass 1 Division 1, Class 1 Division 2

Product Description

Introducing Explosion Proof Fan Atlantic Blowers ABAF-8-110E offers a diverse range of Tube Axial Fans, spanning from 8 inches to 32 inches in blade diameter.

Blower weight: 24lbs.

Note: This intrinsically safe blower will be enclosed in a wood pallet to protect it from damages during shipping. Wood pallet is approximately 70lbs.

Technical Datasheet

Certification & Specification

Hazardous Area Rating

Class 1 Division 1, Class 1 Division 2

Product Overview

Explosion Proof Fan Atlantic Blowers ABAF-8-110E

Introducing Explosion Proof Fan Atlantic Blowers ABAF-8-110E offers a diverse range of Tube Axial Fans, spanning from 8 inches to 32 inches in blade diameter. These fans exemplify top-tier quality and precision, making them versatile for a multitude of applications. With a direct connection between the impeller and the motor shaft, the need for belts and pulleys is eliminated, ensuring an efficient and streamlined operation. Whether you require robust ventilation solutions or reliable air circulation, Atlantic Blowers Tube Axial Fans deliver performance with unparalleled craftsmanship. It can be used for various low pressure and high airflow applications

Features:

Energy Efficiency: Utilizes advanced technology for energy savings.
Portability: Easy to move with a handle or wheels.
Low Noise Operation: Operates quietly (61db-82db).
Lightweight Design: Constructed with Diecast Aluminum Alloy for portability.
Direct Drive Motors: Employs sturdy and powerful direct drive motors.
Optimized Blade Shape: Features lobed axial blade shape for efficient air movement.
Adjustable Airflow: Adjustable blade pitch for customizable airflow.
Class 2 explosion proof motors available - [Ex d IIB T4 Gb]

Versatile Applications:

Welding Fume Exhaust: Effectively removes welding fumes for a safer working environment.
Fume Hood Exhaust: Ensures efficient ventilation in laboratories and industrial settings.
Spot Cooling: Ideal for cooling heat-generating systems precisely.
Paint Spray Exhaust: Efficiently eliminates paint fumes and overspray.
Exhaust Heat/Cooling: Used in kilns, forges, and steel mills for temperature regulation.
Paper Mills: Handles exhaust of mist and vapor in paper manufacturing processes.
Personnel Cooling: Provides relief in hot work environments for enhanced comfort.
Process Cooling: Supports machinery and system cooling during various industrial processes.
Ductwork Boosting: Enhances airflow through long ductwork for improved efficiency.
General Ventilation: Well-suited for general ventilation needs in factories, warehouses, and garages.

Specifications:

Model Number	ABAF-8-110E
Voltage	110-120
KW	0.23
HP	0.3
Speed (RPM)	3300
Weight (lbs)	24
Max Flow (CFM)	1059
Max Pressure ("H2O)	1.2
Sound Level (db)	61
Impeller Diameter	8"
