The Ecom Smart-Ex 01 Instruments is a next-generation touch screen intrinsically safe smartphone that is ATEX and IECEx certified, as well as compliant with the Australian and New Zealand RCM network and electrical safety standards. It is the only 4G/LTE phone certified for usage in Zone 1, Zone 21, and Div 1 hazardous areas. It is SIM-free, which enables connectivity to any network in the world. Smart-Ex 01 underwent quality control in Germany, utilizing 30 years of experience in the Ex-market.
It comes with a 4.0-inch capacitive multi-touch screen protected by Gorilla Glass 2 and dedicated hardware buttons for PTT and LWP operations. The Ecom Smart Ex-01 is powered by an incredibly powerful lithium-ion battery and features a powerful lithium-ion battery, Bluetooth, a 5-pin waterproof magnetic USB, an 8 MP rear camera with autofocus, and a 1 MP front camera. 16GB internal storage and 12GB user memory.
Features:
- ATEX Zone 1
- IECEx
- CSA Class I, II Division 1
- 4G / LTE – standard AT&T and T-Mobile ONLY
- SIM unlocked and free
- Smart-Ex with Camera for North America
- Includes: Charger, Safety Box, Belt Clip and Multi-tool
Specifications:
| General Specifications | |
| Operating System | Android 5.1.1 or Android 4.4.4 |
| Memory | 16 GB Internal Storage / 1GB RAM |
| Expandable SD-Card | Not Available (12 GB Usable Memory Only) |
| Chipset | MSM8926 1.2 GHz Quad core |
| Band | Cellular frequency bands EU variant: 4G LTE: B1, B3, B7, B8, B20, B38 3G UMTS: 850 / 900 / 1900 / 2100 MHz 2G GSM: 850 / 900 / 1800 / 1900 MHz |
| Applications | Google Play Store certified |
| Sensors | G-Sensor, Gyroscope |
| Connectivity | |
| Bluetooth | BT4.0 / BLE (Low Energy) |
| WiFi | 802.11 a / b / g / n dual-band, WiFi Direct, WiFiHotspot |
| GPS | GPS, GLONASS |
| Email Client | EAS, Gmail, POP3, IMAP |
| Physical Characteristics | |
| Ambient Temperature | Smart-Ex 01 -20 °C to +55 °C / Smart-Ex 01M 0 °C to +50 °C |
| Device Weight | 370g |
| Device Size | 137 x 72,1 x 26,9 mm (5.39“ x 2.84“ x 1.06“) |
| Protection Class | IP-68 |
| Ports | 3.5 mm audio connector |
| Screen Size | 4.0 inch |
| Screen Type | Corning Gorilla® Glass 2 with Glove Touch, Blanview Display |
| Battery Capacity (mAh) | 3600 mAh |
| Battery Life | Up to 1000 hours Stand by, up to 40 hours talk time |
| Speaker | 19 mm Loud Speaker with Gore® Protective Vents, Output up to 103 dB |
| Microphone | Dual Mic Solution with Noise cancellation |
| Multimedia | |
| Camera | 8 MP auto focus rear, 1MP fixed focus front |
| Video Streaming | Support AV I, MP4, 3GPP |
The Ecom Smart Ex-01 is equipped with a powerful speaker and a noise-canceling feature. The front and rear cameras enable field video conferencing via live streaming. Complete access to the Google App store and can be used in conjunction with a push to talk or lone worker protection solution.
Smart-Ex 01 Noise Cancellation:
Resources:
- Ecom Smart-Ex 01 Datasheet
- Intrinsically Safe 2019 Ecom Line Card United States
- Intrinsically Safe Products Ecom Latest Products 2019
Important Note: This model is obsolete. Please check the updated model here.
