Intrinsically Safe Computer Zebra Omnii XT15ni

• ATEX Zone 1

• Class I, Division 2
• Groups A,B,C,D
• WEEE compliant
• REACH compliant
• RoHS compliant
• Switchable keyboard
• Windows and Android operating system
• Offers a range of scanning options
• Wi-Fi and Bluetooth connections

Omnii XT15ni is designed for the specialized needs of those requiring safe operation in hazardous environments. The Omnii XT15ni is UL-certified to be non-incendive, providing mobile workers with a rugged handheld device that safely operates in hazardous areas found in pharmaceutical, oil & gas, utilities, chemical, and various manufacturing applications.

The Omnii XT15ni comes with the option of Windows CE 6.0 or Windows Embedded Handheld 6.5 operating systems, both of which integrate seamlessly to automate key processes and boost productivity in real-time. Plus, it is certified IP67 and IP65 and UL-certified to be non-incendive (Class I, Division 2, Groups A,B,C,D; T6) to make it one of the most rugged handheld devices ever made. So you can be sure it will work wherever you take it.

The Omnii XT15ni is built on the proven Omnii platform, meaning it can share the same software and accessories, as well as the majority of options such as imagers, Push-to-Talk speaker, camera, WWAN radio and keyboards as the Omnii’s already deployed across your SCL operation.

Ideal for these industries:

Manufacturing
Utilities
Pharmaceutical
Oil & Gas
Chemical

Physical Characteristics

DIMENSIONS	8.86 in. L x 3.86 in. W x 1.73 in. D (at display);
	1.22 in. D (at grip area)
	225 mm L x 98 mm W x 44 mm D (at display);
	31 mm D (at grip area)
WEIGHT	1.34 lbs./610 g (basic unit with battery)
OPERATING SYSTEM	Windows® CE 6.0; Windows® Embedded Handheld 6.5
CPU	TI OMAP 3, 800 MHz
DROP SPEC	Multiple 6.5 ft./2 m drops to polished concrete

Performance Characteristics

CPU	TI OMAP 3, 800 MHz
Operating System	Windows® CE 6.0; Windows® Embedded Handheld 6.5
Memory	512MB RAM and 1GB Flash ROM
Expansion Ports	MicroSD slot for FLASH expansion
Data Capture Options	SE4500 Standard Range Imager; SE1224HP Std Range Laser; SE1524ER Auto Range Laser
Terminal Emulation	Open TekTerm; Stay-Linked Terminal Emulation;
	Naurtech Browser; Naurtech Terminal Emulation
Mobile VPN	NetMotion Mobility XE VPN
Device Mgmt	Mobile Control Center (MCC)
Software Utilities	PsionVU; Total Recall / TweakIt / Dr. Debug
Voice Applications	Walkie-talkie style Push-to-Talk; VoIP over WiFi or WWAN

User Environment

Operating Temp.	-20°C to +50°C / -4°F to +122°F
Storage Temp.	-40°C to +60°C / -40°F to +140°F
Humidity	5% to 95% non-condensing
Sealing	IP67, IP65, IEC 60529
Drop Spec	Multiple 6.5 ft (2.0m) drops to polished concrete; 5.6 ft (1.7m), 26 drops to polished concrete (powered with options & accessories)
ESD	+/- 8kV contact, +/- 15kV air discharge

Wireless Data Communications

WLAN	IEEE 802.11a/b/g/n, CCX v4: Security 802.1X, WPA / WPA2-Enterprise & Shared Key;
	Authentication: FAST-MSCHAPv2; LEAP; PEAPv0-MSCHAPv2; PEAPv1-GTC; TLS; Encryption: 64/128 WEP, AESCCMP, TKIP
WWAN (optional)	UMTS 3.8G HSPA+ radio:
	Five Band UMTS: 800/850, 900, 1900, 2100 MHz;
	Quad-Band GSM: 850, 900, 1800, 1900 MHz
WPAN	Bluetooth® V2.0 + EDR
GPS (optional)	SIRF III GPS Receiver
