Intrinsically Safe Explosion Proof J&R-JREX106 SIP Telephone
Intrinsically Safe Telephones

Intrinsically Safe Explosion Proof J&R-JREX106 SIP Telephone

In Stock
SKU: JREX106-SIP (SIP/VoIP model)
$1,132.20
Qty
1

Safety Specifications

Incl. accredited factory seal & certification stamps
ZoneZone 1 and Zone 2
Product Description

Introducing the JREX106-SIP phones: reliable communication in hazardous areas of the petrochemical industry. Impact-resistant housing, meeting VoIP standards for critical, safe communications.

Technical Datasheet

Certification & Specification

Country of OriginUnited States (US)
ATEX Safety / ZoneZone 1 and Zone 2

Product Overview

Intrinsically Safe Explosion Proof J&R-JREX106 SIP Telephone

Features:

  • Enables Power-over-Ethernet (PoE 802.3af) or other power sources.
  • Compatible with most SIP-based IP-PBX servers conforming to SIP RFC 3261.
  • Features an industrial-grade housing made of high-impact thermoset resin and an ergonomic heavy-duty handset, meeting IP-66 standards.
  • Offers network web management and full configurability via any internet browser or on-board display, supporting static IP address provisioning or DHCP.
  • Allows product self-diagnostic testing through the web interface.
  • Provides adjustable earpiece volume and microphone sensitivity via the network.
  • Facilitates network downloadable firmware for updates.
  • Allows remote programming, enabling centralized network management.
  • Equipped with corrosion-resistant hardware and a noise-canceling microphone.
  • Utilizes a magnetic reed hook switch to reduce parts subject to wear.
  • Offers direct dialing to assigned locations and a programmable auto hang-up timer.
  • Features a hearing-aid compatible (HAC) receiver.
  • Available with a vandal-resistant armored handset cord or heavy-duty curly handset cord.
  • Incorporates two M20 gland entries.
  • Field-repairable by authorized personnel.

Intrinsically Safe Explosion Proof J&R-JREX106 SIP Telephone

Introducing the JREX106-SIP phones: engineered to provide safe and dependable communication in hazardous areas within the petrochemical industry, including oil, natural gas, and coal production, transportation, and refining. The phones feature a housing constructed from impact and shock-resistant GRP, offering resistance to acids, alkalis, and lubricants. Designed to meet the latest VoIP requirements, they ensure proven reliability in critical communications and high safety applications. These phones prioritize user comfort based on industrial standards and extensive market-leading expertise and know-how.

Specifications:

Electrical Performance:
Network Rate 10/100 Mbps
Protocol SIP (RFC 3261 Compliant)
Connection Direct connection to LAN or WAN via RJ45 connector
Power Requirements Power over Ethernet according to IEEE 802.3af over spare cable pair or external supply, 12V DC
Power consumption PoE (class0)： 2.5 W
M.T.B.F. In excess of 50,000 hours using
Lightning /Transients Protection to ITU-T k.21 enhanced levels
Mechanical Specifications
Hook Switch ( Cradle Switch ) Life >1 000 000 Operations
Housing Material High Impact Glass fibre-reinforced polyeste
Handset Material High Impact Thermoset Resin Compound
Mounting Desk or Wall
Ringing volume: 95dB(A)in 1m distance
Microphone Noise Canceling Electret microphone
Receiver Hearing Aid Compatible (HAC)
Wiring Access 2xM20 Cable Gland Entry Points
Net Weight 6.5kg
Shipping Weight 7.5kg
Unit Dimensions (L x W x D)302x240x129(mm)
Shipping Dimensions (L x W x D)405x280x170(mm)
Packaging materials pearl cotton,carton
Environmental Conditions
Corrosion Resistant & Dustproof Full Gasket Faceplate
Operating Temperature -45˚ to +70˚C
Ingress Protection Rating IP66 according to EN60529
Impact protection IK09 according to EN50102
Humidity 0 to 95% RH

Certifications and Spec Sheet:
