Proteus hazardous site LED lighting fixtures may be used in environments where moisture, dust and corrosion are a problem. Approved for use in applications where abnormal circumstances and places where combustible dust, fibers and flyings are present as stated by the National Electrical Code (NEC) are present. There are two sizes of Proteus: 2’/40W and 4’/80W.. For retrofitting historical H.I.D. and fluorescent lighting systems, the Proteus series provides energy and maintenance reductions that result in a very easy payback.
Features
- Class I Division 2, Group A, B, C, D
- Class II Division 1, Group E, F, G
- Class II Division 2, Group F, G
- Class III
- UL 844 Hazardous Location
- UL 1598 Wet Location
- UL 1598A Marine
- UL 8750 LED Safety
- IP 66 Rated
- Housing: Die-Cast Aluminum *Copper Free
- 40 Watts
- 100-240/277 VAC
- Polyester Powder Coat Finish
- Lens: Polycarbonate
- Meets FCC Part 15, Subpart B, Class B standards for conducted and radiated emissions
Construction
- Heavy-duty die-cast copper-free aluminum housing
- Stainless steel hardware
- 3/4” NPT threaded conduit wire access ports
- Weight – 2’: 11.0 lbs; 4’: 15.2 lbs.
- RoHS Compliant
- Captive bolts on power supply cover
Optical System
- Anodized aluminum reflector assembly with polycarbonate lens
- Diffused polycarbonate lens optional**
- CCT: 5000K, 4000K, or 3000K**
- CRI: 70+
Electrical
- Input voltage of 100-240/277VAC
- The input frequency of 50/60Hz
- Power Factor of ≥.95
- THD <20%
- 10kA surge protector
- Reported L70 hours >50,000
Environmental
- Ambient Operating Temperature -40°F (-40°C) ~ 122°F (50°C)
- C1D2 T3C at 122°F (50°C)
- C2D1 T4A at 122°F (50°C)
- Ambient Operating Humidity of 10%~90% RH
Finish
- RAL 7037 (Dusty Gray) polyester powder coat
Installation
- Prewired with 2’ flying leads
- Allows wiring without opening the power supply cover
- Integrated 3/4” NPT threaded hub for pendant mount
- Universal trunnion bracket available, with legacy bolt pattern (drill rigs)
- Pipe mount kit available
- For installations where power surge may be possible, NICOR recommends installing additional surge
- protection at the electrical distribution panel
Warranty
- 5-year limited system warranty standard
- Warranty does not cover product failure due to an overvoltage event (power surge)
Specifications
| Primary Component Material | Die-Cast Aluminum (Copper Free) |
| Product Color | Dusty Gray |
| Finish | Polyester Powder Coat |
| Product Length (in) | 23.6 |
| Voltage | 100-240/277VAC |
| Wattage | 40.9 |
| Lumen Output | 5533 |
| Lumens Per Watt | 135.3 |
| Color Temperature (CCT) | 5000K |
| CRI | 72 |
| Beam Angle | 120° (+/- 10%) |
| Spacing Criteria | 1.46 |
| 120V Current (A) | 0.341 |
| 277V Current (A) | 0.148 |
| Power Factor | ≥.95 |
| Total Harmonic Distortion (%) | less than 20% |
| Operating Temperature | -40°F to 140°F (-40°C to 60°C) |
| Product Lifespan (Hours) | greater than 50,000 |
| Warranty (Years) | 5 |
