The success of any mobile workforce hinges on productivity and resource utilization. Improved productivity and increased customer satisfaction are the consequence of Janam’s XT2+ rugged handheld computer for mobile workers.
For less than 10 ounces and a 5-inch color display with Corning® Gorilla® Glass 3, XT2+ is a smaller, lighter, quicker, and better rugged mobile computer than any other in its class. 4G LTE connectivity, dual-band Wi-Fi, and a high-sensitivity GPS are just some of its many features.
With the XT2+ handheld computer, mobile workers will be able to work together more effectively on the go. Data collection demands may be met with a single device thanks to high-performance 1D and 2D barcode scanning, as well as RFID and NFC reading capabilities Customers may take high-resolution photos, signatures, and more with the integrated 8.0MP/2.0MP front- and rear-facing color auto-focus cameras.
Features:
- Class I Division II
- Pocket-sized powerhouse weighing only 10 ounces
- Android 6.0
- Brilliant 5-inch color display with Corning Gorilla Glass 3
- High-performance 1D and 2D barcode scanning
- RFID and NFC reading capabilities
- 4G LTE WWAN
- Qualcomm quad-core CPU
- Multiple 5’/1.5m drops to concrete per MIL-STD 810G
- Sealed to IP67 standard against dust and immersion in up to 3 feet of water
- 8.0MP/2.0MP front- and rear-facing color auto-focus cameras
- Dual-band Wi-Fi and Bluetooth 4.0 connectivity
- High-sensitivity GPS
- 3000mAh Li-ion battery
- UL-certified for hazardous locations
Versions:
XT2+: Without GSM/LTE, GPS
- Android 6.x (GMS), RFID/NFC, 2D Imager, 802.11a/b/g/n, Bluetooth, Camera, 2GB/16GB, charging AC adapter, 3000mAh battery, screen protector, stylus, tether
XT2+: With GSM/LTE, GPS
- Android 6.x (GMS), RFID/NFC, 2D Imager, GSM/LTE, 802.11a/b/g/n, Bluetooth, GPS, Camera, 2GB/16GB, charging AC adapter, 3000mAh battery, screen protector, stylus, tether
Specifications
TECHNICAL | |
---|---|
Operating System | Android 6 (XT2+) |
Processor | 1.2 GHz Qualcomm Snapdragon™ 410 quad-core |
Memory | 2GB/16GB |
Expansion | User-accessible microSD card slot with SD and SDHC support |
Power | 3000mAh rechargeable Li-ion battery (4000mAh optional) |
PHYSICAL | |
Dimension | 6.1” L x 3.2” W x .9” D / 155mm L x 83mm W x 24mm D |
Weight | 9.8oz / 279g including battery; 10oz / 293g including battery and MSR |
Display | 5.0” High Definition (720x1280) WXGA with Corning® Gorilla® Glass 3; exceptionally bright, outdoor viewable; anti-raindrop |
Touch Panel | Capacitive touch screen |
ENVIRONMENTAL | |
Operating Temperature | -4º to 140º F / -20º to 60º C |
Storage Temperature | -13º to 158º F / -25º to 70º C |
Humidity | Non-condensing, 95% |
Drop | Multiple 5ft / 1.5m drops to concrete on all sides across a wide temperature range per MIL-STD 810G |
Water & Dust | IP67 |
Vibration | Amplitude 2MM from 10Hz to 33Hz in all three axes, 1 hour per axis |
Electro Static Discharge (ESD) | +/- 15kV air; +/- 8kV contact |
INTERFACE FEATURES | |
Audio | 3.5mm headset jack; speaker; microphone |
Alerts | Vibration; LED indicators |
LED Indicators | Dual-color |
External Buttons | 4 hard keys (home; menu; back button; user-programmable) |
DATA CAPTURE | |
Imager | Zebra SE4710 1D/2D imager (XT2) or Honeywell N6603 1D/2D imager (XT2+) |
Magnetic Stripe Reader | ANSI/ISO-7813 full track; AES-128 CBC mode; DUKPT support |
RFID/NFC | Reads ISO14443 Type A; ISO14443 Type B; MIFARE UltraLight; MIFARE UltraLight C; MIFARE 1k/4k/Plus; MIFARE DESFire; |
MIFARE DESFire EV1; MIFARE DESFire EV2; NFC in the 13.56 MH range | |
NETWORK COMMUNICATION | |
USB | USB 2.0 |
WWAN | PTCRB Certified |
EDGE/GPRS/GSM: 900/1800 | |
WCDMA: B1/2/5/6/8/19 | |
LTE FDD: B1/2/3/4/5/7/8/17/20; LTE TDD: B40/41 | |
WLAN | 802.11a/b/g/n/d/h/i/k/r/v |
Security | IEEE 802.11n; WEP / WPA / WPA2; PEAP/MS-CHAPv2, EAP-TLS |
WPAN | Bluetooth v4.0 |
MOBILE APPURTENANCES | |
Motion Sensor | Gyroscope; Accelerometer; Light Sensor; Proximity Sensor; Digital Compass |
GPS | Qualcomm GPS supports GLONASS |
Camera | 8.0MP color rear-facing autofocus camera with user-controllable LED flash and 2.0MP front-facing camera |
ACCESSORIES | |
Single-Slot USB /Charging Cradle Kit | |
Single-Slot Ethernet Cradle Kit | |
Four-Slot Charging Cradle Kit | |
Four-Slot Battery Charging Kit | |
USB Syncing/Charging Cradle with Locking Screws | |
Charging Adapter | |
Extended Battery Kit | |
Nylon Holster | |
Trigger Handle | |
SAFETY/REGULATORY | |
Safety | IEC 60950; EMC; RF; SAR; LED; Laser |
Radio | FCC; IC; GCF & PTCRB; CE |
Environmental | RoHS and WEEE compliant |
Hazardous Location | UL Listing (US and Canada) Class I Div 2, Groups A, B, C, D |
archeal –
Amazing device powered by quad-core processor. Along with both wifi and 4G LTE for lighting fast connection to voice and data. Plus the options of scanning RFID and NFC reading capabilities. Sealed to IP67 standard.
