Intrinsically Safe Rokee EP-02-G1 Explosion | Flame Proof Lighting

Introducing the Intrinsically Safe Rokee EP-02-G1 Explosion | Flame Proof Lighting luminaries – a cutting-edge solution designed for reliability and efficiency in demanding industrial settings. With benefits including substantial energy savings and reduced maintenance costs, the Explosion-Proof Housing adheres to stringent industry standards, ensuring safety and top-tier performance. Tailored for challenging conditions like moisture, dirt, dust, corrosion, and vibrations, it complies with NEC and IEC specifications for hazardous locations.

Versatile in application, the EP-02-G1 finds its place in refineries, fuel depots, marine vessels, chemical production, food processing, wineries, and other high-humidity, high-temperature, and dusty environments. Beyond adaptability, it stands out for superior efficiency compared to traditional lighting solutions, emphasizing energy savings, lower maintenance costs, and an extended lifespan. This luminary sets a new standard for reliable and cost-effective lighting in challenging industrial landscapes.

Feature:

1. Explosion-Proof Housing:
   • External Proof Construction strictly following standards like EN 60079 and IEC 60079.
   • Unique design structure for strong impact resistance and excellent sealing performance.
   • Suitable for use in hazardous areas such as refineries, fuel depots, marine vessels, chemical production, food processing, wineries, high humidity, and high-temperature dusty places.
2. External Explosion-Proof Construction:
   • Light source and quality driver spaces are designed separately to reduce volume and enhance safety.
   • Threads and potting used for complete separation, strictly following external explosion-proof design.
3. 10mm Tempered Glass:
   • Utilizes 10mm thickness tempered glass for durability, high light transmittance, and strong impact resistance (resisting 4 joule impact).
4. SUS304 Material:
   • All materials are made up of SUS304 stainless steel for stronger corrosion resistance.
5. Perfect Heatsink Design:
   • Light source and quality driver spaces designed separately for better heat dissipation and longer lifespan.
6. ADC 12 Die Casting Housing:
   • Housing made of ADC 12 aluminum alloy through die casting.
   • Incorporates a nicely designed 3D heat dissipation system for effective cooling.
7. Air Convection Design:
   • Utilizes air convection design to speed up the heat dissipation of the lamp.
   • Features a 50% larger dissipation area for enhanced cooling.
8. Wing Slip Bolt for Toolless Beam Adjustment:
   • EP-02 Series boasts a Wing Slip Bolt design, enabling effortless and toolless adjustment of the beam angle.
9. Efficient Toolless Installation:
   • Simplifying the setup process, the series offers toolless installation, ensuring quick and hassle-free deployment in diverse environments.

Specifications:

Item	Power	Effi.	Leds	CRI	Weight	Beam Angle	CCT
EP30W-02-G1	30W	140lm/W	Lumileds	>80	6.95kg(15.32lbs)	60/90/120	3000K/4000K/5000K/5700K
EP50W-02-G1	50W	140lm/W	Lumileds	>80	6.95kg(15.32lbs)	60/90/120	3000K/4000K/5000K/5700K
EP60W-02-G1	60W	140lm/W	Lumileds	>80	7.15kg(15.76lbs)	60/90/120	3000K/4000K/5000K/5700K
EP80W-02-G1	80W	140lm/W	Lumileds	>80	7.15kg(15.76lbs)	60/90/120	3000K/4000K/5000K/5700K
EP100W-02-G1	100W	140lm/W	Lumileds	>80	7.20kg(15.87lbs)	60/90/120	3000K/4000K/5000K/5700K
							3000K/4000K/5000K/5700K
Housing Color	Grey Or Orange	Note: Mention the color while placing the Order
Packaging Specs:	BOX
Mesurement (mm)	Gross Weight	Pcs/box
L380*W350*H275	8.50kg (18.7lbs)	1

Note: Specify the lens optional. Standard= 120 Degree Lens.

Rokee EP-02-G1 Explosion | Flame Proof Lighting

Certificate:

• Rokee -Explaion Proof Lights-ATEX Certificate

Rokee EP-02-G1 Explosion | Flame Proof Lighting

Resources:

• Rokee -Explosion Proof Lights- Contrast Report
• Rokee Explosion Proof Lights -Datasheet
• Rokee Explosion Proof Lights -Brochure
