Description
Titan XPQ1B Hazardous Location (C1D2) LED Flood Light/High Bay
The Titan XPQ1B is a rugged, high-performance LED luminaire specifically engineered for challenging industrial environments where moisture, dirt, dust, and corrosion are constant threats. Designed for NEMA 3 and 4X areas, this fixture is an essential safety component for facilities facing extreme weather, high ambient temperatures, and heavy vibrations.
Built for the field, the Titan offers a high-efficacy retrofit solution for aging HPS/MH systems, delivering significant energy savings and reduced maintenance costs. With available wattages of 80W, 100W, and 150W, it provides flexible, powerful illumination with reported L70 lifetimes exceeding 50,000 hours to ensure long-term operational uptime in critical zones.
Key Features:
✅ UL Class 1 Division 2 (Groups A, B, C, D) & Class 2 Division 2 (Groups F, G) certified
✅ IECEx certified: Ex d IIB T6 Gb / Ex tb IIIC T85°C Db
✅ IP66-rated for superior protection against dust and high-pressure water jets
✅ Heavy-duty die-cast, copper-free aluminum housing with RAL 7037 polyester powder coat
✅ Versatile beam angles: 25°, 60°, and 120° (NEMA Type 2, 4, and 6)
✅ High efficacy performance up to 125.5 Lm/W
✅ Integrated 10kA surge protector for electrical stability
✅ Marine rated (UL 1598A) for offshore and coastal applications
✅ Prewired with 2′ flying leads for easy installation without opening the power supply
📦 Package Options:
🔹 80W Model: Delivered lumens up to 9,240 Lm
🔹 100W Model: Delivered lumens up to 12,170 Lm
🔹 150W Model: Delivered lumens up to 17,261 Lm
🔹 Voltage Options: Standard 100-240/277VAC or High Voltage 347-480VAC
Titan XPQ1B Technical Specifications:
| Feature | Details |
|---|---|
| Wattage Options | 80W, 100W, 150W |
| Hazardous Ratings | C1D2 (Groups A,B,C,D); C2D2 (Groups F,G) |
| International Certs | IECEx Ex d IIB T6 Gb / Ex tb IIIC T85°C Db |
| Input Voltage | 100-240/277VAC or 347-480VAC |
| Efficacy | Up to 125.5 Lm/W |
| Color Temperature | 5000K (Standard), 3000K, 4000K |
| Beam Angles | 25°, 60°, 120° |
| Ingress Protection | IP66 & NEMA 4X |
| Operating Temp | -40°F (-40°C) to 122°F (50°C) |
| Housing Material | Die-cast, copper-free aluminum |
| Hardware | Stainless Steel |
| Lifetime | L70 > 50,000 Hours |
| Warranty | 5-Year Limited System Warranty |
Certifications & Compliance:
🔗 UL844 – Hazardous Location safety standards
🔗 UL 1598 & 1598A – Suitable for Wet Locations and Marine environments
🔗 IECEx – International certification for explosive atmospheres
🔗 IP66 – Complete protection against dust and powerful water jets
🔗Download Datasheet
Applications of Titan XPQ1B:
🔹 Oil & Gas Refineries
🔹 Chemical Processing Plants
🔹 Mining Operations
🔹 Marine & Offshore Platforms
🔹 Heavy Manufacturing Facilities
What’s in the Box?
📦 1x Titan XPQ1B Luminaire
📦 1x Integrated Adjustable Trunnion Bracket
📦 1x 2′ Prewired Flying Leads
📦 1x Documentation Kit
Ordering & Shipping Details
📦 Lead Time: Standard stock items ship within 1-2 weeks; consult the factory for specialized CCT or High Voltage lead times.
📍 Shipping Terms: Worldwide / Expedited Options
💳 Payment Options: Credit Card, PayPal, Net 30 Terms
Related Products:
🔗 Heavy Duty 3′ Safety Cable (XP1DSCABLE-3)
🔗 Titan Wire Guard (XPQ1WG)
🔗 Titan Slip-Fitter Mount (XPQ1SLIPFITGR)
FAQs:
Can this fixture be mounted on a pendant?
Yes, the Titan features an integrated 3/4″ NPT threaded hub specifically for pendant mounting.
Is this light suitable for saltwater environments?
Absolutely. It is UL1598A Marine rated and constructed with copper-free aluminum and stainless steel hardware to resist corrosion.
What happens if there is a massive power surge?
While the unit includes a 10kA surge protector, NICOR recommends additional protection at the distribution panel; the 5-year warranty does not cover overvoltage events.
Are different lens types available?
Yes, while tempered glass is standard, a diffused lens is available as an option (consult factory for lead times).
