SENKO IR Link Infrared Communication & Management Interface

The SENKO IR Link serves as an essential wireless communication bridge between SENKO portable gas detectors and Windows-based PC software. Utilizing optical infrared line-of-sight telemetry, this USB-powered interface allows safety technicians to quickly retrieve event logs, configure alarm thresholds, and perform routine calibrations without requiring physical cable connections to the gas detector body. It provides a fast, secure, and seamless solution for compliance reporting and instrument fleet management across oil & gas, chemical, and industrial processing facilities.

Designed for demanding field servicing and benchtop calibration environments, the SENKO IR Link features a high-visibility, impact-resistant orange polymer housing. Power is supplied directly via the host PC's USB port (5V bus powered), eliminating the need for external power sources or batteries. High-speed parameter synchronization and data extraction occur at a simple alignment distance of ~1 cm from the gas detector's IR port, with dual LED status indicators providing real-time visual feedback during power-up, optical handshakes, and active data transmission.

Key Features:

✅ Direct Optical Infrared Telemetry — High-speed, wireless line-of-sight data transfer without physical cable connection
✅ 5V USB Bus Powered — Connects directly to host PC; no external power supplies or batteries required
✅ High-Impact Industrial Housing — Rugged, high-visibility orange polymer built for benchtop labs and field maintenance
✅ Real-Time LED Status Indicators — Blue LED blinks during data transfer; Red LED indicates power-up/handshake
✅ Complete Fleet Management — Download CSV data logs, program STEL/TWA limits, update firmware, load .cfg profiles
✅ Automated Calibration & Bump Test Scheduling — Digital Zero/Span calibrations programmable interval alerts (0–365 days)
✅ Multi-Device Compatibility — Fully supports SENKO SGT, SGT-P, MGT, SP-MGTP, and MGT Docking Station II

📦 Package Options:

🔹 Standard USB Kit: Includes SENKO IR Link Module with integrated USB host connection cable

SENKO IR Link Technical Specifications:

Feature	Details
Product Type	Infrared Communication & Management Interface
Host Interface	USB Port (5V Bus Powered)
Wireless Interface	Optical Infrared (IR) Telemetry
IR Alignment Distance	~1 cm (line-of-sight to gas detector IR sensor)
Encryption	Proprietary Protocol Encryption
Status Indicators	Blue LED (Data Transfer) / Red LED (Power & Handshake)
Enclosure Construction	High-visibility, impact-resistant orange polymer housing
Supported Gas Detectors	SENKO SGT, SGT-P, MGT, SP-MGTP and MGT Docking Station II
Software Compatibility	Official SENKO IR Link Software Docking Manager (Windows PC)
Key Functions	Data log/event extraction (CSV) alarm threshold management (STEL/TWA/Low/High), Zero/Span calibration, bump test scheduling (0–365 days) firmware flashing, configuration profile loading (.cfg)

Certifications & Compliance:

🔗 USB Serial Optical Interface — Proprietary protocol encrypted optical line-of-sight communication
🔗 Industrial Enclosure — High-visibility, impact-resistant polymer housing for lab and field use
🔗 Download Datasheet

Applications of SENKO IR Link:

🔹 Oil & Gas
🔹 Chemical Plants
🔹 Mining
🔹 Labs
🔹 Manufacturing

What’s in the Box?

📦 1x SENKO IR Link Module (with USB Host Cable)
📦 1x Quick Start / Technical Documentation Kit

Ordering & Shipping Details

📦 Lead Time: 1 -2 weeks
📍 Shipping Terms: Worldwide / Expedited Options
💳 Payment Options: Credit Card, PayPal, Net 30 Terms

Related Products:

🔗 SENKO SGT Disposable Single-Gas Detector
🔗 SENKO SGT-P Replaceable Single-Gas Detector
🔗 SENKO MGT Multi-Gas Detector (4-Gas)
🔗 SENKO MGT Docking Station II

FAQs:

How far should the SENKO IR Link be placed from the gas detector during data transfer?
The IR Link optical window should be aligned directly facing the gas detector's IR port at a distance of approximately 1 cm. Ensure both optical windows are clean and free of dust or grease before transferring data.

Does the SENKO IR Link require batteries or an external power source?
No, the SENKO IR Link is fully powered via the 5V USB bus directly from your PC.

Can I use the IR Link to update instrument firmware?
Yes, the SENKO IR Link software allows you to flash the latest device firmware onto compatible SENKO detectors, as well as deploy standardized configuration (.cfg) profiles across your fleet.

Is the IR Link compatible with the MGT Docking Station II?
Yes, for station software synchronization and automated log offloading, insert the IR Link into Bay 1 of the MGT Docking Station II.
