Zone 1DATCON DT9100 Digital Clock

The DATCON DT9100 is an ATEX-certified intrinsically safe digital clock specifically engineered for dependable, precise time synchronization in Zone 1 and Zone 2 hazardous areas. Designed for harsh processing environments across oil & gas, chemical production, and offshore platforms, this industrial unit provides unambiguous local visual timekeeping while meeting strict explosive-atmosphere safety mandates.

Equipped with a high-accuracy crystal oscillator delivering typical accuracy within ±1 minute per year, the DT9100 features a large 4-digit liquid crystal display (25.4 mm character height) visible across active work floors. Field configuration is simplified with three front-panel push buttons protected by a two-level password system, offering flexible synchronization via a 4–20 mA current loop, an external IS digital input, or local manual control.

Key Features:

✅ ATEX Certificate  II (1) 2G Ex ia IIC T5 / T6 Gb for Zone 1 and Zone 2 hazardous areas
✅ High-precision crystal oscillator with typically less than ±1 minute error per year
✅ Large 4-digit LCD with 25.4 mm character height in HH: MM format
✅ Available as field-mount housing (IP65) or standard DIN panel-mount (IP65 front / IP30 rear)
✅ Flexible power options: Intrinsically Safe 4.5 V battery pack or 4–20 mA loop-powered
✅ Internal time backup retains accurate time for up to 60 minutes during power interruption or battery swap
✅ Two isolated digital outputs for automated alarm and status signaling
✅ Three selectable synchronization modes (local push-button, IS digital input, or 4–20 mA current loop control)
✅ Two-level password security against unauthorized parameter adjustment

📦 Package Options:

🔹 DT9100 14: Wall-mount polycarbonate enclosure (IP65), 4–20 mA loop-powered

DATCON DT9100 Technical Specifications:

Feature	Details
Product Models	DT9100
Hazardous Area Certification	BKI 18 ATEX 0007 X
ATEX Protection Marking	Battery models (B): II (1) 2G Ex ia IIC T5 (-20°C < Ta < +60°C) Loop-powered models (14): II (1) 2G Ex ia IIC T6 (-20°C < Ta < +60°C)
Installation Zones	Zone 1, Zone 2, or Safe Area
Display Type	4-digit Liquid Crystal Display (LCD), HH:MM format
Character Height	25.4 mm (1.0 inch)
Time Display Range	00:00 to 23:59
Display Refresh Rate	1 second
Time Accuracy	±1 minute error per year (typically, at Ta 0°C to 40°C)
Power Supply Options	• Intrinsically Safe 4.5 V internal battery pack (3+ year continuous runtime) Intrinsically Safe 4–20 mA loop-powered
Power Backup Time	Up to 60 minutes upon battery swap or loop interruption
Synchronization Modes	• Local: 3 front-panel push buttons• Remote (Battery versions): IS digital input Remote (Loop versions): 4–20 mA signal control (14–20 mA range triggers sync)
Security	Two-level password-protected menu system
Alarm / Digital Outputs	2 isolated passive switching transistor outputs (Max 10 V, 16 mA Ex safety data)
Housing Material	DT9100: Moulded polycarbonateDT9102: DIN standard ABS case (144 x 72 mm cutout)
Ingress Protection (IP)	DT9100: IP65 complete enclosureDT9102: IP65 front bezel / IP30 rear terminals
Operating Temperature	-20°C to +60°C
Relative Humidity	Up to 90% RH (maximum, non-condensing)
EMC Compliance	EN 61326: Immunity for industrial areas; Emission Group 1, Class B
Wiring & Terminals	DT9100: IP65 cable entry, push-in direct connections (0.25–1.5 mm²)
Dimensions (W x H x D)	DT9100 Field Instrument: 167 x 111 x 71 mm
Unit Weight	DT9100: 0.5 kg

Certifications & Compliance:

🔗 ATEX Certificate BKI 18 ATEX 0007 X – Certified for explosive gas environments
🔗 Protection Marking: II (1) 2G Ex ia IIC T5 (Battery version) / T6 (4–20 mA version)
🔗 EN 61010-1 & EN 61326  – Industrial EMC immunity and low RF emissions (Group 1, Class B)
🔗 Ingress Protection – IP65 full enclosure (DT9100) or IP65 front / IP30 rear (DT9102)
🔗 Download Datasheet

Applications of DATCON DT9100:

🔹 Oil & Gas
🔹 Chemical Plants
🔹 Mining
🔹 Labs
🔹 Manufacturing

What’s in the Box?

📦 1x DATCON DT9100 Intrinsically Safe Digital Clock
📦 1x Internal IS Battery Pack (Pre-installed with "B" models)
📦 1x Panel/Wall Mounting Hardware Kit
📦 1x Push-in Terminal Connection Block Set
📦 1x Cable Gland (DT9100 Field Enclosure)
📦 1x Quick Start Guide
📦 1x Documentation Kit & ATEX Certificate of Conformity

Ordering & Shipping Details

📦 Lead Time:  2 - 3 weeks
📍 Shipping Terms: Worldwide / Expedited Options
💳 Payment Options: Credit Card, PayPal, Net 30 Terms

Related Products:

🔗 DATCON Replacement IS Battery Unit (BAT) – Dedicated 4.5 V replacement pack

FAQs:

How long does the internal battery last on the battery-powered version?
The internal intrinsically safe battery pack (DT9100 B / DT9102 B) powers the unit continuously for at least three years, with minimal shelf-life loss (approx. 1% per year at 20°C).

Will the clock lose time during a battery replacement or loop shutdown?
No. Both models incorporate an internal backup system that retains time and configuration data for up to 60 minutes when disconnected from power.

How can the clock be synchronized remotely?
Battery-operated models support synchronization via an intrinsically safe digital input, while loop-powered models synchronize using the 4–20 mA current loop (4–10 mA standard operation, 14–20 mA synchronization signal).

Can unauthorized operators change the time or settings in the field?
No. The front push-button menu system is secured by a two-level password to prevent unauthorized adjustments.
