LED Explosion Proof Flood Light - High Efficiency with Lumileds 5050 and IP66 Protection

The LED Explosion Proof Flood Light is engineered to provide powerful, reliable lighting in hazardous environments. Equipped with high-efficiency Lumileds 5050 chips and rugged low-copper aluminum alloy housing, this floodlight is ideal for areas requiring explosion-proof lighting, such as chemical plants, oil refineries, and offshore platforms. It offers a high luminous efficiency of over 130 lm/w, robust surge protection, and is certified for Zone 1, 2, 21, and 22 applications.

Key Features:

• Chips: Lumileds 5050 for high luminous efficiency
• Efficiency: >130 lm/W for bright, energy-saving illumination
• Driver: Meanwell drivers for stable performance
• Wide Voltage: Operates on 90-305VAC with 6kV surge protection
• Durability: IP66-rated and T6 temperature class for extreme environments
• Body: Low-copper aluminum alloy with cooling fins for heat dissipation
• Glass: Shock and temperature-resistant tempered glass
• Beam Angles: Available in 30°, 60°, 90°, and 120° options
• Total Harmonic Distortion (THD): <20% for smooth operation
• Inrush Current: <65A

Applications:

Ideal for use in hazardous areas like oil refineries, offshore platforms, chemical industries, and any Zone 1, 2, 21, and 22 environments. Certified for Class I, Division 1 & 2, and Class II, Division 1 & 2 settings, this light provides reliable, safe illumination in explosive atmospheres.

Specifications:

Ordering Code	Rated Power	LED Quantity	Beam Angle	Luminous Flux
CSEXHFL80	80W	68 (Lumileds 5050)	30°, 60°, 90°, 120°	10400lm
CSEXHFL100	100W	84 (Lumileds 5050)	30°, 60°, 90°, 120°	13000lm
CSEXHFL120	120W	84 (Lumileds 5050)	30°, 60°, 90°, 120°	15600lm
CSEXHFL150	150W	84 (Lumileds 5050)	30°, 60°, 90°, 120°	19500lm
CSEXHFL160	160W	84 (Lumileds 5050)	30°, 60°, 90°, 120°	20800lm
CSEXHFL180	180W	84 (Lumileds 5050)	30°, 60°, 90°, 120°	21600lm
CSEXHFL200	200W	84 (Lumileds 5050)	30°, 60°, 90°, 120°	24000lm

Package Includes:

• LED Explosion Proof Flood Light
• U-bracket for mounting
• User manual

Benefits:

• Safe for use in hazardous areas, with multiple certifications ensuring compliance with international safety standards.
• High energy efficiency, delivering bright light while saving on energy costs.
• Durable construction with shock-resistant glass and corrosion-resistant materials ensures a long lifespan.
• Flexible installation with multiple mounting options and beam angles to suit various applications.

Resources and Certifications:

• Certifications: ATEX, IECEx, PCEC, CE, RoHS
• Datasheet

Accessories:

• U-bracket for wall or ceiling mounting
• Optional mounting poles

More Options for You:

• Intrinsically Safe CS-EXHB86-SM LED EXPLOSION PROOF LIGHT

• LED EXPLOSION PROOF HIGH BAY LIGHT

• CS-EXHB720-SM LED EXPLOSION PROOF LIGHT

• Underground Mine Explosion Proof Type LED Light (Group I)

Extra Information:

Warranty: 5-year limited warranty.
