AE Light 25W Xenide AEX25-EP HID Explosion Proof Lights

Out of Stock

SKU: AEX25-EP

$638.52

Safety Specifications

Hazardous AreaClass 1 Division 2

Product Description

These 25W Xenide AEX25-EP HID Explosion Proof Lights are utilized in places where petrochemical or dust particles may occur and the danger of igniting exists. Explosion proof lighting is classified as Class 1, Division 1/2, or Class 2, Division 1/2 by UL standards. Offshore lights, rig lights, spray booths, cleaning boats, fuel cells, plant turn around, maritime work areas, grain storage, dust, or explosives are examples of these locations.

Technical Datasheet

Certification & Specification

Hazardous Area Rating

Class 1 Division 2

Product Overview

The AE light Xenide AEX25-EP, also known as 25W HID Explosion Proof Lights, Intrinsically Safe, and Hazardous Location portable lighting, has been tested to the performance procedures contained in the UL 783, for use in Hazardous (Classified) locations including:

Class 1, Division 2, Groups A, B, C, and D and Class 1, Division 2, Groups A, B, C, D;
Class 2 Division 2, Groups F and G;
and Class 2 Division 2, Groups F and G

As defined in the National Electric Code, NFPA 70, the device's light covers the requirements for intended use in Hazardous locations.

According to the results of the tests, the Xenide AEX25-EP meets the requirements for satisfactory operation in an explosive environment and will not cause an explosive atmosphere to ignite under normal operating conditions. As a result, there is no harm, danger, or significant results.

Features:

Color Temperature: 6500K±
Run time: 130 minutes
Length: 13.5 in., 343 mm
Weight: 32oz., 907 gm
Light head: 3 in., 76.2 mm
Handgrip: 1.5 in., 38 mm
Power Supply: Rechargeable 4800mAh waterproof Lithium Ion,
Power Switch: Push-button on/off
Beam: 12deg. fixed
Lumens: 1500+-
Rating: IP68 (Totally protected against dust and protected against long periods of immersion under pressure).
Light body: Black hard-anodized aircraft-grade aluminum
Chargers: 100/240VAC 50/60Hz, Optional DC 12-24VDC w/overcharge protection, LED indicator

Light set includes*: Light head, 4800mAh waterproof power pack, AC charger, charger stand, lens and end cap protectors, lens cloth, black plastic molded travel/storage case *(filters, spare battery & DC charger not included).
