Ion Science GasClam 2 is a unique in-hole gas monitoring device that is approved for use in hazardous regions by ATEX Zone 1. Ensured by IECEx certification. Atmospheric, subterranean, and groundwater pressures and levels are all monitored by GasClam 2, which also measures unmanned continuous ground gas concentration data. This data reduces the amount of mystery surrounding what lies beneath the surface. It is possible to forecast future changes in the ground gas regime by tracking the current process of managing it.
pecuniary incentives can be found at several levels in GasClam 2. The first cost-cutting measure is a reduction in the number of field engineer visits. As regulatory data requirements are satisfied more quickly, the time of monitoring programs can be reduced. In order to save the most money, it is important to develop solutions that are appropriate rather than over-engineered.
Features:
- ATEX ZOne 1
- IECEx
- Stainless Steel case
- Battery Life:
- Lithium primary cell – 3 months
- Alkaline cell – 1 month
- Rechargeable battery pack – 1 week
- IP68
- European and World Wide patented
Specifications:
| GAS | METHOD/TYPE | RANGE | RESOLUTION | ACCURACY |
| CO2** | Infrared | 0-100% | 1% above 50% | ± 2% FSD |
| 0.5% below 50% | ||||
| CO2** | Infrared | 0-5% | 0.05 above 2.5% | ± 2% FSD |
| 0.025 below 2.5% | ||||
| CH4** | Infrared | 0-100% | 1% above 50% | ± 2% FSD |
| 0.5% below 50% | ||||
| CH4** | Infrared | 0-5% | 0.05 above 2.5% | ± 2% FSD |
| 0.025 below 2.5% | ||||
| O2 | Electrochemical | 0-25% | 0.001 | ± 5% of reading |
| CO | Electrochemical | 0-2000 ppm | 1 ppm | <± 3 ppm at 0 |
| ± 5% at 250 ppm | ||||
| ± 10% full scale | ||||
| H2S* | Electrochemical | 0-100ppm | 1 ppm | ± 1 ppm at 0 |
| ± 2.5% at 50ppm | ||||
| VOC* | PID | 0-4000 ppm | 1 ppm | ± 5% of reading |
| ± 1 digit | ||||
| DUAL CO/H2S | ||||
| CO | Electrochemical | 0-500ppm | 1ppm | <± 3ppm at 0 |
| ± 3% at 250ppm | ||||
| H2S | Electrochemical | 0-200ppm | 1ppm | <± 1 ppm at 0 |
| ± 2% at 100ppm | ||||
| ENVIRONMENTAL | METHOD/TYPE | RANGE | RESOLUTION |
| Barometric Pressure | Piezoelectric | 800 to 1250 mBar | 1 mBar |
| Borehole Pressure | Piezoelectric | 800 to 1250 mBar | 1 mBar |
| Temperature | Internal Chip | -5°C to +50°C or | 0.1°C or 1°F |
| 22°F to 122°F | |||
| Water Depth* | Piezoelectric | 0 — 25m | 0.01 m |
| (various available) |
| Power Options | Internal: Option of Lithium primary cells or Duracell Alkaline D-Cells or |
| Rechargeable battery pack | |
| External: Accepts intrinsically safe external power supply for extended | |
| and/or rapid monitoring | |
| Typical Battery | Lithium primary cells – 3 Months |
| Life (hourly sampling) | Alkaline cells – 1 Month |
| Rechargeable battery pack – 3 Weeks | |
| Case | High quality stainless steel |
| Dimensions | Overall length: 90cm (35.4 in) |
| Borehole tube length: 83cm (32.6 in) | |
| Head diameter: 11cm (4.3 in) | |
| Borehole tube diameter: 4.7cm (1.85 in) | |
| Weight | 7.5kg (16.8 lbs) |
| Protection | IP68 rated (continuous submersion) |
| Operation Temp. | -20oC to 50oC (-4oF to 122oF) |
| Approvals | EMC, ATEX 0105 X |
| CE | |
| Ex II 2G Ex d ib [ib] IIB T4 Gb | |
| IECEx d ib [ib] IIB T4 Gb | |
| CSA C (US & Canadian Approvals) | |
| Class 1, Zone 1 (A) Ex d id IIB T4 | |
| Patents | European and World-wide Patented |
| * Optional | |
| ** Choice of 2 IR sensors, specify on order. |
