Intrinsically Safe James Industry C Series Explosion Proof Lights

Intrinsically Safe James Industry C Series Explosion Proof Lights are approved for use in ATEX Zone 1/21, Class I Division I, Class I Division II, Class II Division I, as well as in both Class II Division I and Class II Division II hazardous areas. IECEx and marine-grade components are on board. To provide general illumination in hazardous locations, this luminaire can be utilized as a downlight, tunnel light, floodlight, and wall pack for general illumination. This product’s versatility allows it to cater to diverse industries and challenging settings where reliability and performance are critical.

Features:

• Dimmable & Battery Backup: (D) Offers dimming and includes a battery backup for emergencies.
• High-Quality Components: (@) Equipped with premium SMT LED and a reliable Meanwell driver.
• Durability & Replaceability: (G) Boasts heavy-duty, impact-resistant design, with replaceable LED boards and drivers.
• Integrated Junction Box: (G) Includes an integrated junction box for the driver.
• Marine-Grade Finish: (@) Features a marine-rated powder-coated finish for durability.
• Installation Versatility: (G) Offers various installation methods for different applications.
• Lens Options: (@) Provides options for glass or polycarbonate lenses to adjust beam angles.
• Emergency Battery Backup: Indicates an available emergency battery backup for continued functionality during power outages.
• 5-Year Warranty: Provides assurance with a 5-year warranty coverage.
• Wide Operating Temperature Range: (♦) Operates in a broad temperature range from -40°C to 60°C (-40°F to 140°F) and is compatible with ATEX & IECEx (IC solution) from -40°C to 80°C (-40°F to 176°F), ensuring functionality in various environmental conditions.

Applications:

• Oil and Gas Industry: Covers the entire spectrum from production, refining, transportation, storage, and retail, including LNG operations and mining services.
• Ocean, Marine, and Aerospace: Applicable in ocean platform operations, aerospace clean rooms, vessel operations, and marine structures.
• Food and Alcohol: Essential in flour and fine particle production/storage, food processing, and within the alcohol industry.
• Chemical Industry: Applied in paint facilities, chemical production, and storage areas.
• Metal Treatment: Ideal for steel and aluminum factories, pumping stations, metal smelting, foundry, and fabrication settings.
• Challenging Environments: Suitable for high-humidity, high-dust, high-temperature, and vapor-rich locations.

James Industry C Series Explosion Proof Lights

Specifications:

Technical Data
Product Number	Wattage	Voltage	Lumens (Im)	Efficiency (Im/W)	CRI	CCT	Emergency Time
EX-20W C2YZDA	20W	AC100-277V/DC12-48V,AC200-480V	2800	140	>70	2200K-7000K	3 hours
EX-40W C2YZDA	40W	AC100-277V/DC12-48V,AC200-480V	5600	140	>70	2200K-7000K	3 hours
EX-60W C2YZDA	60W	AC100-277V/DC12-48V,AC200-480V	8400	140	>70	2200K-7000K	3 hours
EX-80W C2YZDA	80W	AC100-277V/DC12-48V,AC200-480V	11200	140	>70	2200K-7000K	3 hours
EX-100W CYZDA	100W	AC100-277V/DC12-48V,AC200-480V	14000	140	>70	2200K-7000K	3 hours
EX-120W CYZDA	120W	AC100-277V/DC12-48V,AC200-480V	16800	140	>70	2200K-7000K	3 hours
EX-150W CYZDA	150W	AC100-277V/DC12-48V,AC200-480V	21000	140	>70	2200K-7000K	3 hours
EX-180W CYZDA	180W	AC100-277V/DC12-48V,AC200-480V	25200	140	>70	2200K-7000K	3 hours
EX-200W C3YZDA	200W	AC100-277V/DC12-48V,AC200-480V	28000	140	>70	2200K-7000K	3 hours
EX-240W C3YZDA	240W	AC100-277V/DC12-48V,AC200-480V	33600	140	>70	2200K-7000K	3 hours
EX-250W C3YZDA	250W	AC100-277V/DC12-48V,AC200-480V	35000	140	>70	2200K-7000K	3 hours
EX-280W C3YZDA	280W	AC100-277V/DC12-48V,AC200-480V	39200	140	>70	2200K-7000K	3 hours

Certification & Resources:

• James Industry C Series Certification & Datasheet
