Description
NICOR PROTEUS XPL1A 3’ Heavy Duty DS Safety Cable
The NICOR PROTEUS XPL1A, 3’ Heavy Duty DS Safety Cable, is a specialized industrial LED luminaire engineered for the most demanding hazardous environments, including Class I, Division 1 and Division 2 locations. This rugged linear fixture provides essential safety and high-visibility lighting for oil and gas facilities, chemical plants, and industrial sites where explosive vapors and gases may be present.
Designed for extreme durability and performance, the XPL1A features a wide operating temperature range from -40°C to +60°C and an IP66 environmental rating, ensuring reliable operation in wet and harsh conditions. Its versatile design supports multiple mounting configurations—including surface, pendant, and stanchion—and includes quick-connect wire connectors to simplify complex field installations and through-wiring applications.
Key Features:
✅ Hazardous Location Certified: Class I, Division 1, Groups C, D, and Class I, Division 2, Groups A, B, C, D
✅ Multi-Voltage Support: Rated for 100-240/277VAC or 347/480VAC at 50/60Hz
✅ Extreme Weather Performance: Ambient temperature range of -40°C to +60°C (-40°F to 140°F)
✅ Ingress Protection: IP66 rated and suitable for wet locations
✅ High-Quality Construction: Features an external glass lens and integrated cooling fins for thermal management
✅ Simplified Maintenance: Includes 5mm drive hex retention bolts and internal quick-connect wire connectors
✅ Reliable Optics: LED light output maintained above 70% with color temperature shifts limited to 200K CCT
✅ Safety First: Integrated secondary retention through-holes for secure carabiner attachment
✅ Industrial Longevity: Backed by a 5-year LED Express Limited Warranty
📦 Package Options:
🔹 Standard Voltage (100-277VAC): Suitable for most commercial and industrial power grids
🔹 High Voltage (347-480VAC): Specialized for heavy industrial and Canadian power standards
🔹 Surface Mount: Requires trunnion bracket (sold separately)
🔹 Stanchion Mount: Kit sold separately for 2″ or 2.5″ pipe diameters
NICOR PROTEUS XPL1A Technical Specifications:
| Feature | Details |
|---|---|
| Product Name | NICOR PROTEUS XPL1A Hazardous Location Linear LED |
| Hazardous Ratings | Class I, Div 1 (Groups C, D); Class I, Div 2 (Groups A, B, C, D) |
| Input Voltage | 100-240/277VAC or 347/480VAC, 50/60Hz |
| Operating Temp | -40°C to +60°C (-40°F to 140°F) |
| Ingress Protection | IP66 (Dust-tight and protected against powerful water jets) |
| Environmental | Suitable for wet locations |
| Compliance | UL 844, UL 1598, UL 1598A, CSA C22.2 |
| Mounting Options | Surface, Pendant (3/4" NPT), or Stanchion (2" / 2.5") +2 |
| Wiring | Terminal block and internal quick-connect wire connectors +1 |
| Warranty | 5-Year Limited LED Express Warranty |
| Construction | External glass lens with integrated thermal cooling fins +1 |
Certifications & Compliance:
🔗 Brochure Nicor Lighting
🔗 UL 844 – Standard for Luminaires for Use in Hazardous (Classified) Locations
🔗 UL 1598 / 1598A – Standards for Luminaires and Supplemental Requirements for Marine Vessels
🔗 CSA C22.2 – Canadian standards for luminaires and hazardous location equipment
🔗 IP66 Rating – Complete protection against dust and high-pressure water jets
🔗 Download Datasheet
Applications of NICOR PROTEUS XPL1A:
🔹 Oil & Gas (Refineries and Drilling Platforms)
🔹 Chemical Plants and Storage Facilities
🔹 Mining and Heavy Industrial Environments
🔹 Labs and Pharmaceutical Manufacturing
🔹 Manufacturing in Volatile Atmospheres
What’s in the Box?
📦 1x XPL1A Hazardous Location Fixture
📦 1x 3-wire pigtail (installed)
📦 1x 3/4″ NPT plug (for unused conduit ports)
📦 2x 6mm drive hex bolts & lock washers (mounting hardware)
📦 2x 3mm drive hex set-bolts (angle adjustment)
📦 1x Documentation and Installation Instructions
Ordering & Shipping Details
📦 Lead Time: 1 – 2 Weeks
📍 Shipping Terms: Worldwide / Expedited Options
💳 Payment Options: Credit Card, PayPal, Net 30 Terms
Related Products:
🔗 NICOR Trunnion Mounting Bracket
🔗 Stanchion Pipe Mount Kit (2″ – 2.5″)
🔗 Secondary Retention Cable Kit
FAQs:
What is the warranty period for the XPL1A?
The fixture comes with a five-year limited warranty covering the LED electronics and components.
Can this fixture be used in wet environments?
Yes, it is IP66 rated and explicitly listed as suitable for wet locations.
What is the operating temperature range?
The XPL1A is designed to operate in ambient temperatures between -40°C and +60°C.
Who should install this equipment?
Installation must be performed by a qualified licensed electrician in accordance with the NEC and local codes.
