The Intrinsically Safe Portable Gas Detector SENKO SGT is intended to detect oxygen, hazardous, and flammable gases in the surrounding environment and is certified ATEX Zone 0, Class I Division I. With IECEx and KCS certifications. To keep employees safe from oxygen deprivation or exposure to hazardous gases, the SGT may run for up to two years without the need for a new battery or gas sensor.
Among the many useful functions of SGT, when active, it continually checks the air for the presence of certain gas and notifies the user if gas concentrations surpass the alarm setpoints through LED, vibration, and audio alarms. SENKO IR Link may also be used to alter the alert threshold, calibration range, and display settings (Optional).
Shock protection, automated sensor troubleshooting, data logging (up to 30 occurrences), and a superb waterproof/dustproof construction are also included.
Features:
- ATEX Zone 0
- Class I Division I
- IECEx
- Disposable Type
- compact and lightweight
- event log (30EA)
- maintenance-free
- operates continuously for 2 years
- easy configuration and data management through SGT-IR Link
- easy calibration through Docking Station
- high performance audible, visual, vibration alarm
- Setting 1st, 2nd alarm
- Limited Warranty: 2 years from the date of purchase
- IP67
Specifications:
| Model | SGT | |||
| Measuring gas | O 2 | CO | H 2 S | H 2 |
| Range | 0~30%Vol | 0~500ppm | 0~100ppm | 0~1000ppm |
| Model | SGT | |||
| Measuring gas | SO 2 | NH 3 | Cl2 | NO 2 |
| Range | 0~20ppm | 0~100ppm | 0~20ppm | 0~20ppm |
| Model | SGT | ||||||
| Sensor Type | Electrochemical | ||||||
| Measurement | Diffusion type | ||||||
| Display | LCD display | ||||||
| Audible | 90dB at 10cm | ||||||
| Warning Lamp | Red Flashing LEDs (Light-Emitting Diode) | ||||||
| Vibration | Vibration Alarm | ||||||
| Battery | Manufacture: Vitzrocell / P/N: SB-AA02(P) / System: Lithium Primary Battery 3.6V / 1.2Ah | ||||||
| Temperature & Humidity | -40ºC ~ +50ºC(for Toxic) / -35ºC ~ +50ºC(for O 2 ) 5%~95% RH (Non-condensing) | ||||||
| Case | Rubber Enclosure | ||||||
| Accessories | Calibration Cap, Manual, Calibration and Quality report | ||||||
| Option | External Sampling Pump (SP-Pump101), SENKO-IR Link, Docking Station | ||||||
| Size & Weight | Size: 54(W) × 91(H) × 32(D)mm / Weight: 93g(Toxic), 104g(O 2 ) (Battery, clip included) | ||||||
| Operating Life | 24 months, based on 2 minutes of alarm per day | ||||||
| Event Log | Recent 30 alarms | ||||||
| Approval | Ex ia IIC T4Ga/ IP67 (Korea Ex, IECEx, ATEX, CSA & UL, INMETRO) |
