Shenzhen CES-J100 Hazardous Location LED Flood Light-IS

Introducing the Shenzhen CES-J100 Hazardous Location LED Flood Light-IS – a robust lighting solution designed for hazardous environments. Constructed with a housing made of high-strength aluminum alloy and tempered glass, this floodlight exhibits exceptional vibration and impact resistance. The efficient heat dissipation structure ensures the lamp’s durability against high mechanical strength and temperature fluctuations.

Featuring a versatile range of installation methods, including optional emergency capabilities with a 1.5-hour backup battery, this explosion-proof lamp is ideal for hazardous location lighting. The sealed structure of this series enhances its waterproof and anti-corrosion performance, achieving UL1598A Marine Grade certification. The hazardous location LED floodlight is suitable for use in Class I, Division 2, Groups A, B, C, and D hazardous locations, providing a reliable and long-lasting lighting solution in challenging environments.

Features:

• Innovative Curved Fin Shape Design with patented technology for optimal heat transmission.
• Constructed with high-quality Aluminum Alloy (ADC12) for enhanced durability.
• Utilizes LM80 certified LEDs with a luminous efficacy of 130 lm/W +5, providing up to 24050 lm.
• Equipped with a tempered glass lens that is shock and vibration resistant, ensuring over 90% light transmission.
• Employs a Meanwell LED Driver with over 90% driver efficacy for efficient and reliable performance.
• Circuit design incorporates 4KV/6KV Surge Protection for power supply resilience.
• Boasts IP67 protection grade, delivering high-level waterproof and dust-proof capabilities.

Application:

• Oil & Gas Exploration
• Drilling
• Oil Refinery
• Petrochemical Plant
• Power Plant
• Pharmaceutical Plant
• Heavy Industrial Storage Facility
• Paper Mills
• Wastewater Treatment Plants
• Shipyards

Certificate and Standard:

Hazardous Location Certifications (NEC/CEC):

• Class I, Division 2, Groups A, B, C, and D compliance
• T-Class: T6
• Suitable for use in damp and wet locations
• Certificate No: E475887
• US: UL 844; UL 1598
• Canada: CSA C22.2 No. 137; CSA C22.2 No. 250.0

Marine Certifications:

• Certificate No: E495071
• Compliant with relevant standards for marine applications (specific standards not provided in the information)

Warranty:

• 5 Years Warranty

Shenzhen CES-J100 Hazardous Location LED Flood Light

Emergency Back up Optional:

• Emergencypower:12W,
• Emergency time:>90min,
• Battery: Li-ionbattery-11.1V/2500mAH

Operation Highlights:

AC Operation:

• LED load powered by the normal supply from the LED driver when AC power is present.
• AC LED driver output current capped at 150W or 4A.
• Emergency driver charges in standby mode, indicated by a green LED light.

Emergency Operation:

• Automatic switch to emergency mode during AC power outage, marked by the green LED turning off.
• Upon AC power restoration, the emergency driver returns to AC power operation and begins recharging, with the green LED light indicating the process.

Shenzhen CES-J100 Hazardous Location LED Flood Light

Specifications:

Shenzhen CES-J100 Hazardous Location LED Flood Light

Certificate:

• E495071 for Marine
• E357786 for wet locations
• E475887 for hazardous location
• ATEX cert.
• IECEX Cert.
• UL844 Cert.

Shenzhen CES-J100 Hazardous Location LED Flood Light

Resources:

• Datasheet
