Guardian Equipment GFR3100 Eyewash Station

SKU: GFR3100

An Eyewash Station that is intrinsically safe the Guardian Equipment GFR3100 with top inlet is ideal for applications that require warm water. It’s a two-in-one heat-traced safety station with self-limiting heat tracing cables wrapped around the internal pipe to give superior protection against freezing. The GFR3100 from Guardian Equipment is approved for usage in Class 1 Division 2 hazardous locations with cold weather.

Delivery time is approximately 11-12 weeks for this specially formulated unit

Hazardous Area Rating


Trusted Clients

  • Logo PH66
  • Logo  Exxon
  • Logo Bp
  • Logo Conoco Phillipis
  • Logo Irwing
  • Logo Bayer
  • Logo Tesoro
  • Logo Northen TIer
  • Logo Udelhoven
  • Logo Aloha petroleum
  • Logo Rand
  • Logo Arrow Energy
  • Logo Schlumber
  • Logo Afton
  • Logo Holly frontier
Similar Categories: ,

Guardian Equipment’s GFR3100 emergency eyewash station with top inlet is ideal for locations that require warm water. Electrically heated emergency eyewash and shower safety station set on the floor with a top inlet and an ABS plastic showerhead with an internal flow control of 20 GPM.


  • Class I Division 2
  • Floor mounted electrically heat traced emergency eyewash station with a top inlet
  • Self-regulated with external termination guards
  • The thermostat activates when the internal piping temperature falls below 75°F
  • Unit is fully wired at the factory
  • UV-resistant orange ABS plastic with polyethylene foam insulation
  • 10″ diameter orange ABS plastic with 20 GPM flow control
  • ” IPS brass stay-open ball valve. US-made with brass ball and PTFE seals
  • Freeze-resistant with float-off dust covers and internal flow control
  • 1” IPS U.S. made brass stay-open ball valve with stainless steel actuating arm
  • ½” IPS U.S. made brass 3-way self-draining stay-open ball valve
  • 1¼” IPS Schedule 40 hot-dipped galvanized pipe and fittings
  • Polished stainless steel pull rod, stainless steel flag handle and powder coated cast aluminum floor flange
  • Self-regulating electric heat-traced cable
  • UV-resistant ABS plastic jacket with foam insulated core and weather-sealed with elastomeric material
  • 120VAC, 60 HZ single phase power supply
  • Pipe sensing thermostat (optional freeze protection valve, “FP”)
