Intrinsically Safe Signal Conditioner

The Intrinsically Safe Signal Conditioner KFD2-STC5-1.2O is a high-reliability isolator for safe signal transmission from hazardous to safe areas. Designed for ATEX and IECEx Zone 0/20 use, it supports analog signal loops, ensuring galvanic isolation between input, output, and power supply. This signal conditioner is perfect for integrating 2-wire transmitters and active sensors into control systems in oil & gas, chemical, and process automation environments.

Supporting 4–20 mA analog loops with loop-powered operation, the device does not require an external power source. It features a slim DIN rail design, ideal for compact control cabinets, and delivers stable, maintenance-free signal conditioning in extreme industrial conditions. This makes it a go-to solution for isolating field instrumentation and ensuring signal integrity in hazardous locations.

Key Features:

✅ ATEX & IECEx Zone 0/20 Certified
✅ 4–20 mA Analog Signal Transmission
✅ Galvanic Isolation (Input/Output/Power)
✅ Passive Loop-Powered Operation
✅ Compact DIN Rail Mount Design
✅ No External Power Supply Needed
✅ Compatible with PLC and DCS Systems
✅ High Accuracy and Low Signal Drift
✅ Maintenance-Free, Long-Term Stability

📦 Package Options:

🔹 Standard Unit: 1x Signal Conditioner + Manual
🔹 10-Pack: Ideal for cabinet installations
🔹 Custom Integration Kits: Available upon request
🔹 DIN Rail Mounting Accessories: Optional clips and terminals

Intrinsically Safe Signal Conditioner Technical Specifications:

Feature	Details
Model	KFD2-STC5-1.2O
Signal Type	Analog 4–20 mA
Power Supply	Loop-powered (no external supply required)
Mounting	DIN rail
Input	2-wire transmitters / active sensors
Output	Isolated analog signal
Isolation	Galvanic (input/output/power)
Certifications	ATEX, IECEx Zone 0/20
Dimensions	20 mm wide module
Housing	Plastic, compact industrial design

Certifications & Compliance:

🔗 ATEX – Certified for Zone 0/20 applications in explosive gas/dust atmospheres
🔗 IECEx – Global standard for intrinsic safety compliance
🔗 Galvanic Isolation – Protects control systems from field faults
🔗 Passive Loop Power – Operates without external power source
🔗 Download Datasheet

Applications of Intrinsically Safe Signal Conditioner:

🔹 Oil & Gas
🔹 Chemical Plants
🔹 Mining
🔹 Labs
🔹 Industrial Automation

What’s in the Box?

📦 1x Intrinsically Safe Signal Conditioner (KFD2-STC5-1.2O)
📦 1x User Manual
📦 1x Certificate of Compliance

Ordering & Shipping Details

📦 Lead Time: 4-6 Weeks
📍 Shipping Terms: Worldwide / Expedited Options
💳 Payment Options: Credit Card, PayPal, Net 30 Terms

FAQs:

Can this conditioner be used in Zone 0?
Yes, it is certified for ATEX and IECEx Zone 0/20 environments.

Is it compatible with 2-wire transmitters?
Yes, it’s designed to interface safely with 2-wire field devices.

Does it require a power supply?
No, it operates passively from the signal loop.

What kind of isolation does it provide?
It provides galvanic isolation between input, output, and power.

Is this a Zener barrier?
No — this is an isolated signal conditioner, also known as an isolated barrier. It offers intrinsic safety by isolating the hazardous and safe area circuits without requiring grounding, unlike Zener barriers.

When should I use an isolated barrier instead of a Zener barrier?

Use isolated barriers like this when:

• You need galvanic isolation between field and control systems

• Grounding is not possible or practical

• You require signal accuracy (4–20 mA loops, PLCs, SCADA)

• You’re operating in Zone 0/20 environments
