Intrinsically Safe Camera CorDEX TC7000

SKU: 9027504020
(1 customer review)

ATEX and IECEx Certified Intrinsically Safe Camera CorDEX TC7000. Passed CorDEX ToughTEST. 6 hours continuous run-time. CorDEX CONNECT enabled. Glove friendly controls. 8GB file storage.

ATEX Rating

$8,49500

Trusted Clients

Similar Category:
Need Help?

Speak with a Hazardous Area expert now

832 699 6726 | Chat us

Description

Intrinsically Safe Camera CorDEX TC7000

  • ATEX Zone 1
  • IECEx
  • M2 explosive areas
  • High resolution 320 x 240 IR Detector
  • Onboard RFID tag reader
  • CorDEX CONNECT enabled
  • Temp Range: -20 → +600 °C
  • 8GB file storage



Intrinsically Safe Camera TC7000 by CorDEX is a popular choice of thermal imaging camera among oil, gas, mining, marine and dust facilities. Why? It is the first fully radiometric ATEX Zone 1 and IECEx certified ergonomically designed infared camera that is built to take HD images in hazardous and highly explosive environments. It is one of the first thermal camera with the latest generation of SMART Infrared Window which operates with any thermal imager. It find the smallest defects with the high resolution 320 x 240 IR Detector and it can rotate to shoot over and under targets easily and quickly. The clear and bright 3.2” backlit display allows user to see hot spots easily plus it is very robust, it passed the drop, dust and water tests.

TC7000 Thermal Imaging Camera – Tough TEST



Certificate Information
ATEX / IECEx Certificate NoTRAC12ATEX0037X / IECEx TRC 12.0019X
ATEX / IECEx Certificate Types• Ex ib IIC T4 Gb Tamb -10°C to +40°C (Vapor)
• Ex ib IIIC T200°C Db Tamb -10°C to +40°C (Dust)
• Ex ib I Mb (Mining)
Temperature Information
Measurement Range-4°F to 1112°F (-20°C to +600°C )
Accuracy± 2°C or 2% of reading
Imaging
Image Frequency9Hz
Detector320 x 240 uncooled microbolometer
Thermal Sensitivity/NETD50mK
Spectral Range8μm to 14μm
Field of View (FOV)25° x 20.5°
Spatial resolution (IFOV)1.38 mrad
Minimum focus distance≈ 4” (10cm)
LensF 1.2
Image Capture
File Storage8GB
File FormatsCDX (Radiometric) JPEG (Non-radiometric)
Voice AnnotationYES
RFID Tag Reader• Operates with 13.54MHz passive tags
• Detection range up to 5cm (1.9in)
• SupportsISO/IEC15693-2,ISO/IEC18000-3 tag formats
General
Operating Temperature-4°F to 104°F (-20°C to +40°C)
Storage Temperature-40°F to +158°F (-40°C to +70°C)
Display3.2” Backlit LCD
SoftwareCorDEX CONNECT (Included)
BatteriesRechargeable Lithium-ion

Why Choose CorDEX Intrinsically Safe Camera TC7000?

It is tested for toughness.  It passed CorDEX ToughTEST including water, dust and repeated drops. Assign RFIO data to images for automatic collation and reporting with CorDEX CONNECT software. It features Built-in RFID tag
reader for use 13.5 Mhz RFID tags and also with the CorDEX SMART IR Windows. It is integrated with high speed manual focus lens that is capable to resolve minute detail with highly sensitive manual focus lens. The articulating head allows user to see over, under and around obstacles without moving the display. It has long life Lithium ion battery, up to 6 hours continuous run-time with rechargeable Lithium ion battery pack. And most importantly, it has large, glove friendly controls designed to operate in virtually any environment.

Intrinsically Safe Camera CorDEX TC7000 Certifications:

Intrinsically Safe Camera CorDEX TC7000 Other Resources:

Product Accessories

Make Your Job Easy. Try Our Most Popular Accessories

CorDEX Mains Adaptor – CDX2341-130 TC

CorDEX Mains Adaptor – CDX2341-130 TC

SKU: 85299020

CorDEX Mains Adaptor CDX2341-130 TC is designed for intrinsically safe camera TC series including TC7000 and TC7150.

Brand: CorDEX

In Stock 7-10 business days

$20000

Reviews & Questions

Share your thoughts!

5 out of 5 stars

1 review

Let us know what you think...

What others are saying

  1. Pam

    You will love this camera

    Pam

    This Intrinsically Safe Camera comes with a very handy user guide, the buttons are very responsive. It is ATEX Zone 1 rated and is everything you want in a rugged Intrinsically Safe camera.
