Intrinsically Safe Ethernet Coupler SOLEXY BXF3S0101XN018

SKU: BXF3S0101XN018
(1 customer review)

The Intrinsically Safe Ethernet Coupler Solexy BXF3S0101XN018 is a certified Zone 1 Class I Div 1 and IECEx ethernet coupler that allows for transmissions of Ethernet into hazardous areas with a standard RJ45 connector. Can be installed with a simple wrench and no potting compounds and made from 300 series stainless that protects the fitting from corrosive environments. It can be hot connected or disconnected without powering down the system. The cable installation and removal can be accomplished without removing power.

ATEX Rating

Hazardous Area Rating

IECEx Certified

$76600

Shipping Time: 4 weeks

Need faster options? Contact our Hazardous Areas Experts now for quick alternatives!

Trusted Clients

  • Logo PH66
  • Logo  Exxon
  • Logo Bp
  • Logo Conoco Phillipis
  • Logo Irwing
  • Logo Bayer
  • Logo Tesoro
  • Logo Northen TIer
  • Logo Udelhoven
  • Logo Aloha petroleum
  • Logo Rand
  • Logo Arrow Energy
  • Logo Schlumber
  • Logo Afton
  • Logo Holly frontier
Similar Category:

Intrinsically Safe Ethernet Coupler SOLEXY BXF3S0101XN018

  • ATEX Zone 1
  • IECEx
  • Class I Division 1
  • No Sealing Fitting Required
  • Corrosion Resistant
  • Environmental Protection
  • Interchangeability
  • Industrial M12 “D” connection
  • Cable length: 18″ 0,45 mt CAT5e
  • AISI303 stainless steel
  • Thread connection: 3/4″ NPT
  • Suitable for hazardous area
  • Housing Connector: Shielded M12 Female “D” coded
  • Housing Material: 300 SST(approximate weight 0,38kg (0.83lb))
  • Protection: 3.6 V
  • Maximum Fault Voltage: RMS 250 V
  • Ambient Temperature range: -40°C (-40°) to +85°C (+185°F) (T4) and -40°C(-40°F) to +60°C (+140°F) (T5)
Introducing the Intrinsically Safe Ethernet Coupler Solexy BXF3S0101XN018 is an ethernet coupler certified Atex Zone 1, Class 1 Div 1 and IECEx ratings that allows for transmissions of Ethernet into hazardous areas with a standard RJ45 connector. With the Solexy Ethernet coupler, it’s possible to connect any standard ethernet devices located in a classified or safe area. This device is certified for installation in classified areas. Designed to be used with any USA&Canada, ATEX or IECEx listed explosion proof housing without the need of a seal fitting, taking up no internal space.
Solexy’s patented (7,057,105) Explosion-Proof / Intrinsically Safe Ethernet Coupler allows for transmissions of Ethernet into hazardous areas with a standard RJ45 connector. A BXF and/or BAF coupler is required on each end of a cable installation for full protection of both the RX and TX lines.

Intrinsically Safe Ethernet Coupler Solexy BXF3S0101XN018 Certifications:

Intrinsically Safe Ethernet Coupler Solexy BXF3S0101XN018 Other Resources:

Reviews & Questions

Share your thoughts!

5 out of 5 stars

1 review

Let us know what you think...

What others are saying

  1. Sales Intrinsically Safe Store

    Sales Intrinsically Safe Store

    This is the most trusted barrier in its class, the Intrinsically Safe Ethernet Coupler Solexy BXF3S0101XN018 is an ethernet coupler certified Atex Zone 1, Class 1 Div 1 and IECEx ratings that allow for transmissions of Ethernet into hazardous areas with a standard RJ45 connector. It is now possible to connect any standard ethernet devices located in a classified or safe area.
