Spectrum F112-NBN73023BA-BD Explosion-Proof Fixed Camera
Features:
Spectrum Explosion-Proof Fixed Camera
Casing
- IP66-rated, powdercoated aluminum chassis
- Casing manufactured and certified by Spectrum Camera Solutions, LLC
| Technical Data | |
| Model | Spectrum F112-NBN73023BA-BD |
| Sensor (1080p version) | |
| Sensor Type | 1/2,8-inch CMOS |
| Effective Pixels | 1920 (H) x 1080 (V); 2MP (approx) |
| Sensor | BOSCH NBN-73023-BA |
| Starlight sensitivity | |
| Color | 0.0069 lx |
| Mono | 0.0008 lx |
| Dynamic Range - HDR Mode | |
| High Dynamic Range (10-bit, 3x exposure) | 120 dB WDR |
| Measured according to IEC 62676 Part 5 | 110 dB WDR |
| Video Streaming | |
| Video compression | H.264 (MP); M-JPEG |
| Video Content Analysis | |
| Analysis type | Intelligent Video Analytics |
| Configuration | Silent VCA / Profile 1 / Profile 2 / Event Triggered / Scheduled |
| Alarm rules (combinable) | Any object Object in field Crossing line Entering field Leaving field Loitering FolloWing route Idle object Removed object Counter Occupancy CroWd detection Condition change Similarity search Tampering |
| Object in field | |
| Crossing Line | |
| Entering field | |
| Leaving field | |
| Loitering | |
| Following route | |
| Idle Object | |
| Removed Object | |
| Counter | |
| Occupancy | |
| Crowd detection | |
| Condition Change | |
| Similarity search | |
| Tampering | |
| Object filters | Duration |
| Size | |
| Aspect ration v/h Speed | |
| Direction | |
| Color | |
| Object classes ( Upright persons, Bikes, Cars, Trucks) | |
| Lens Option: LVF-5003C-P2713 | |
| Sensor SiZe | 1/2.7 in. |
| Resolution | 3 MP |
| Iris Range | F1..4 - close |
| Focal length | 2.7 - 13mm |
| Lens Mount | CS |
| Lens Connector | 4 pin P-iris Control |
| Dimensions | 47mm X 75mm |
| Zoom Control | Manual |
| Focus Control | Manual |
| Technical Specs of Camera with regard to lens | |
| Sensor SiZe | 1/2.7 in. |
| Resolution | 1920(H) X 1080(V) (approX 2 MP) |
| Lens Mount | CS (can use C With adaptor ring) |
| Lens Connector | Standard 4 pin DC iris connector |
| Lens Types | Standard DC-Iris auto-detect With override DC Iris Drive |
| General | |
| Casing | Aluminum |
| Weight | 6.4 kg (14 lb) |
| Dimensions | 13.85 x 7.20 x 6.01 in (352 x 183 x 153 mm) |
| Power | 57 VDC, 7.2W; 12-24 VAC/VDC 25W |
| Storage Conditions | -30°C to +70°C Humidity 5-98% RH (non-condensing) |
| Operating Conditions | Zone system: -50°C to +50°C (USA) Class/Division system: -40°C to +50°C Humidity 10-100% RH (condensing) |
| Warranty | 5-year limited warranty, see spectrumcamera.com/warranty |
| Approvals | Hazardous Area |
| FM3600, FM3615, ANSI/ISA/EN/IEC/CAN/ | |
| CSA-C22.2 60079-0, ANSI/UL/EN/IEC/CAN/ | |
| CSA-C22.2 60079-1, ANSI/UL/IEN/EC/CAN/ | |
| CSA-C22.2 60079-31 | |
| EMC | |
| EN 55032 Class A, EN 50121-4, IEC 62236-4, | |
| EN 55024, EN 61000-6-1, EN 61000-6-2, FCC | |
| Part 15 Subpart B Class A, ICES-003 Class A, | |
| VCCI Class A, RCM AS/NZS CISPR 32 Class A, | |
| KC KN32 Class A, KC KN35 | |
| Safety | |
| IEC/EN/UL 60950-22, IEC/EN/UL 62368-1, IS 13252 | |
| Environment | |
| IEC 60068-2-1, IEC 60068-2-2, IEC 60068- 2-6, IEC 60068-2-14, IEC 60068-2-27 | |
| IEC 60068-2-78, IEC/EN 60529 IP66/IP67, IEC/EN 62262 IK10, NEMA 250 Type 4X, NEMA TS 2 (2.2.7-2.2.9) | |
| Network | |
| NIST SP500-267 | |
| Explosion-proof Certifications | USA: |
| Class I Division 1 Groups BCD T6 Ta= -40°C to +50°C, Type 4X, IP66 | |
| Class II/III Division 1 Groups EFG Ta= -40°C to +50°C, Type 4X, IP66 | |
| Certificate: FM18US0262X | |
| Canada: | |
| Class I Division 1 Groups BCD T6 Ta= -50°C to +50°C, Type 4X, IP66 | |
| Class II/III Division 1 Groups EFG Ta= -50°C to +50°C, Type 4X, IP66 | |
| Class I, Zone 1, AEx/Ex db IIB+H2 T5 Gb Ta = -50°C to +50°C, Type 4X, IP66 | |
| Zone 21, AEx/Ex tb IIIC T85°C Db Ta = -50°C to +50°C, Type 4X, IP66 | |
| Certificate: FM18CA0126X | |
| ATEX: | |
| II 2 G Ex db IIB+H2 T5 Gb Ta = -50°C to +50°C, IP66 | |
| II 2 D Ex tb IIIC T85°C Db Ta = -50°C to +50°C, IP66 | |
| Certificate: FM18ATEX0073X | |
| IECEx: | |
| Ex db IIB+H2 T5 Gb Ta = -50°C to +50°C, IP66 | |
| Ex tb IIIC T85°C Db Ta = -50°C to +50°C, IP66 | |
| Certificate: IECEx FMG 18.0029X | |
