Durabook Z14I C1D2 Rugged Laptop
The Durabook Z14I C1D2 is a rugged 14″ laptop built for high-performance computing in Class I Division 2 hazardous environments. Whether you’re operating in oil refineries, chemical facilities, or utility infrastructure, the Z14I provides AI-powered processing, sunlight-readable display, and superior durability to meet the demands of industrial fieldwork.
With a choice of Intel® Core™ Ultra 5 or Ultra 7 processors, built-in Intel® AI Boost NPU, and advanced connectivity (Wi-Fi 7 + Bluetooth 5.4), this rugged device is engineered for real-time data acquisition, control system management, and mobile diagnostics. Glove-compatible touch, TPM, IP66 sealing, and 3-year accidental damage coverage round out its industrial-grade toolset.
Key Features:
✅ Class I, Division 2 Certified – Safe for North American hazardous locations
✅ Windows 11 Professional – Optimized for field productivity
✅ IP66 & MIL-STD protection – Fully rugged with extreme water/dust resistance
✅ Advanced Connectivity – Wi-Fi 7, Bluetooth 5.4, Thunderbolt 4, HDMI, VGA, RJ45 x2, RS232 x2
✅ Camera – 2.0 MP front-facing webcam
✅ TPM & Smart Card Reader – Secure hardware-level encryption
✅ AI Boost NPU – Intel® Ultra processors for next-gen AI workloads
✅ Backlit Keyboard – Field-ready usability in low light
✅ Sunlight-Readable Display – 1200 nits brightness touchscreen
✅ 3-Year Accidental Damage Warranty – Field-resilient service guarantee
📦 Package Options:
🔹 Basic Model : Intel® Core™ Ultra 5 125U, 16GB RAM, 256GB SSD
🔹 Standard Model: Intel® Core™ Ultra 7 155U, 16GB RAM, 256GB SSD
Durabook Z14I C1D2 Technical Specifications:
| Specification | Z14I Basic | Z14I Standard |
|---|---|---|
| Processor | Intel® Core™ Ultra 5 125U | Intel® Core™ Ultra 7 155U |
| Processor Speed | Up to 4.3 GHz | Up to 4.8 GHz |
| Cores / Threads | 12 cores / 14 threads | 12 cores / 14 threads |
| NPU (AI Boost) | Yes | Yes |
| Operating System | Windows 11 Professional | Windows 11 Professional |
| RAM | 16GB | 16GB |
| Storage | 256GB PCIe SSD | 256GB PCIe SSD |
| Display | 14" FHD (1920 x 1080) Touchscreen | 14" FHD (1920 x 1080) Touchscreen |
| Brightness | 1200 nits | 1200 nits |
| Touchscreen | Yes | Yes |
| Wi-Fi | Wi-Fi 7 | Wi-Fi 7 |
| Bluetooth | Bluetooth v5.4 | Bluetooth v5.4 |
| Keyboard | Backlit | Backlit |
| Smart Card Reader | Yes | Yes |
| Webcam | 2.0 MP | 2.0 MP |
| Ports | 2x RJ45, 2x RS232, 2x Thunderbolt 4 | 2x RJ45, 2x RS232, 2x Thunderbolt 4 |
| Video Outputs | HDMI, VGA | HDMI, VGA |
| Security | TPM, Smart Card Reader | TPM, Smart Card Reader |
| Ingress Protection | IP66 | IP66 |
| MIL-STD | MIL-STD-810H | MIL-STD-810H |
| Warranty | 3-Year Accidental Damage Coverage | 3-Year Accidental Damage Coverage |
Certifications & Compliance:
🔗 Class I Division 2 – Certified for use in potentially explosive atmospheres
🔗 IP66 – Total protection against dust and high-pressure water jets
🔗 MIL-STD-810H – Resists shock, vibration, and extreme environments
🔗 TPM – Trusted Platform Module for security assurance
🔗 Download Datasheet
Applications of Durabook Z14I C1D2:
🔹 Oil & Gas
🔹 Chemical Plants
🔹 Utilities & Power Plants
🔹 Public Safety
🔹 Industrial Automation
What’s in the Box?
📦 1x Durabook Z14I C1D2 Laptop
📦 1x Battery Pack
📦 1x Power Adapter
📦 1x Power Cord
📦 1x Stylus or Touch Pen (if applicable)
📦 1x Documentation Kit
📦 1x Rugged Carrying Handle
Ordering & Shipping Details
📦 Lead Time: 1-2 weeks
📍 Shipping Terms: Worldwide / Expedited Options
💳 Payment Options: Credit Card, PayPal, Net 30 Terms
FAQs:
Is the Durabook Z14I certified for Class I Division 2?
Yes, both Basic and Standard models are fully C1D2 certified for use in North American hazardous areas.
What’s the difference between the Basic and Standard models?
The Standard model features a higher-performance Intel® Core™ Ultra 7 155U processor, while the Basic model uses the Intel® Core™ Ultra 5 125U.
Can I use this laptop with gloves?
Yes, the touchscreen is glove-compatible for field safety and usability.
Does it come with a warranty?
Yes, both models include a 3-year Durabook Accidental Damage Warranty for peace of mind.
Specifications
| Display: | 14.0” FHD (1920 x1080) 1000 nits DynaVue® sunlight readable display with capacitive multi-touch screen User selectable touch mode for Finger/Water, Glove, or Stylus programmable function |
| Operating System: | Windows® 10 Pro |
| Processors: | Intel® Core™ i7-8650U vPro™ (8th Gen) 1.9GHz processor with Turbo Boost Technology up to 4.2GHz, 8MB cache |
| Intel® Core™ i7-8550U (8th Gen) 1.8GHz processor with Turbo Boost Technology up to 4.0GHz, 8MB cache | |
| Intel® Core™ i5-8350U vPro™ (8th Gen) 1.7GHz processor with Turbo Boost Technology up to 3.6GHz, 6MB cache | |
| Intel® Core™ i5-8250U (8th Gen) 1.6GHz processor with Turbo Boost Technology up to 3.4GHz, 6MB cache | |
| Memory: | 2 slots 8GB up to 32GB (2400MHz DDR4) |
| Storage: | 256GB SSD |
| Optional 512GB / 1TB SSD | |
| Optional OPAL 2.0 SSD | |
| Optional 2nd storage (SSD)1 | |
| Graphics: | Intel® UHD Graphics 620 |
| Camera: | Integrated 2.0 MP web-cam with shutter design |
| Audio: | Integrated microphone |
| Intel® High Definition Audio Compliant | |
| Integrated speaker x 2 | |
| Keyboard volume and mute controls | |
| Media Bay: | Optional DVD super multi |
| (One Option Only) | Optional 2nd battery |
| Optional 2nd storage (SSD)1 | |
| Expansion Box: | Optional PCI-Express 2.0 (2 slots)1 |
| (One Option Only) | Optional discrete VGA1 |
| Optional Military-grade Connector1 | |
| Optional Storage Extension with RAID 0/1/5/101 | |
| I/O Ports: | USB 3.1 (type A) x 2 |
| USB 3.1 (type C) x 1 | |
| USB 2.0 (type A) x 1 | |
| Audio in/out (combo jack) x 1 | |
| microSD card (microSDXC) x 1 | |
| 10/100/1000 Ethernet (RJ-45) x 2 | |
| VGA port (D-sub,15-pin) x 1 | |
| DP port x 1 | |
| HDMI port (type A) x 1 | |
| Serial port (RS-232 : D-sub, 9-pin) x 25 | |
| Docking connector (41-pin Pogo) x 1 | |
| SIM card x 1 | |
| Smart card reader x 1 | |
| DC-In jack x 1 | |
| PCMCIA Type II x1 | |
| ExpressCard 54 x1 or PCMCIA Type II x1 | |
| Optional RF antenna pass-through for GPS, WWAN, and WLAN | |
| Keyboard & Pointing Device: | 2 user-definable keys (P1/P2) |
| RF signal slide-switch | |
| Standard membrane keyboard with LED backlight | |
| Communications: | Integrated 10/100/1000 Ethernet |
| Intel® Dual Band Wireless AC 9260 (802.11a/b/g/n/ac) | |
| Bluetooth® V5.0 | |
| Optional dedicated GPS module (UBLOX-NEO-M8N) | |
| Optional 4G LTE multi-carrier mobile broadband | |
| Optional RF antenna pass-through for GPS, WWAN, and WLAN | |
| Security: | Intel® vProTM Technology (per CPU options) |
| TPM 2.0 | |
| NIST BIOS compliant | |
| Easy removable SSD | |
| Smart card reader default | |
| Stealth mode | |
| Night vision mode | |
| Kensington lock | |
| Optional fingerprint scanner | |
| Optional HF/LF RFID reader1 | |
| Power: | AC adapter : 100-240V, 50Hz-60Hz, 90W Main battery Li-Ion, 10.8V, 7800mAh, 16 hours2 Optional 2nd battery Li-Ion 10.8V, 4700mAh, 9 hours2 Optional bridge battery : 5 minutes swap time3 |
| Dimension & Weight: | 356 mm (L) x 280 mm (W) x 50 mm (H)4 |
| 3.6 kg4 | |
| Warranty: | 3-year limited warranty standard |
