Description
Ecom Smart-Ex 01
- ATEX Zone 1
- IECEx
- CSA Class I, II Division 1
- 4G / LTE – standard AT&T and T-Mobile ONLY
- SIM unlocked and free
- Smart-Ex with Camera for North America
- With SureLock license and installation
- Includes: Charger, Safety Box, Belt Clip and Multi-tool
Ecom Smart-Ex 01 Instruments is the latest generation touch screen smartphone that is certified by ATEX and IECEx along with Australian and New Zealand RCM network and electrical safety compliance. It is the only 4G/LTE cell phone to carry a Zone 1, Zone 21 and Div 1 certifications for hazardous area use. It is SIM free which allows connection to any network worldwide. Quality control of Smart-Ex 01 was conducted in Germany based on 30 years experience in the Ex-market.
It features a 4.0“ capacitive multi-touch screen made of extreme shock and scratch resistant Gorilla Glass 2 and dedicated hardware buttons for PTT and LWP functions. The Ecom Smart Ex-01 runs on Android 5.1 operating system and is supported with a powerful lithium-ion battery, Bluetooth, 5-pins waterproof magnetic USB, 8 MP rear camera with auto focus and 1 MP front camera. Huge internal storage capacity of 16GB and 12GB user memory.
Proper Use of Sim Card
| General Specifications | |
| Operating System | Android 5.1.1 or Android 4.4.4 |
| Memory | 16 GB Internal Storage / 1GB RAM |
| Expandable SD-Card | Not Available (12 GB Usable Memory Only) |
| Chipset | MSM8926 1.2 GHz Quad core |
| Band | Cellular frequency bands EU variant: 4G LTE: B1, B3, B7, B8, B20, B38 3G UMTS: 850 / 900 / 1900 / 2100 MHz 2G GSM: 850 / 900 / 1800 / 1900 MHz |
| Applications | Google Play Store certified |
| Sensors | G-Sensor, Gyroscope |
| Connectivity | |
| Bluetooth | BT4.0 / BLE (Low Energy) |
| WiFi | 802.11 a / b / g / n dual-band, WiFi Direct, WiFiHotspot |
| GPS | GPS, GLONASS |
| Email Client | EAS, Gmail, POP3, IMAP |
| Physical Characteristics | |
| Ambient Temperature | Smart-Ex 01 -20 °C to +55 °C / Smart-Ex 01M 0 °C to +50 °C |
| Device Weight | 370g |
| Device Size | 137 x 72,1 x 26,9 mm (5.39“ x 2.84“ x 1.06“) |
| Protection Class | IP-68 |
| Ports | 3.5 mm audio connector |
| Screen Size | 4.0 inch |
| Screen Type | Corning Gorilla® Glass 2 with Glove Touch, Blanview Display |
| Battery Capacity (mAh) | 3600 mAh |
| Battery Life | Up to 1000 hours Stand by, up to 40 hours talk time |
| Speaker | 19 mm Loud Speaker with Gore® Protective Vents, Output up to 103 dB |
| Microphone | Dual Mic Solution with Noise cancellation |
| Multimedia | |
| Camera | 8 MP auto focus rear, 1MP fixed focus front |
| Video Streaming | Support AV I, MP4, 3GPP |
Ecom Smart Ex-01 is supported with an extremely loud speaker and a noise cancelling function. The front and back cameras allow live streaming video conferencing in the field. Full access to Google App store and can be used a part of push to talk or lone worker protection solution.
Smart-Ex 01 Noise Cancellation:
Ecom Smart-Ex 01 Certifications:
- Ecom Smart-Ex 01 EAC Certification
- Ecom Smart-Ex 01 Korean Certification
- Ecom Smart-Ex 01 NCC Certification Brazil
- Ecom Smart-Ex 01 CSA Certification North America
- Ecom Smart-Ex 01 Ecom ATEX I Certification Germany
- Ecom Smart-Ex 01 ATEX I Certification United Kingdom
- Ecom Smart-Ex 01 IECEx International Certification
Pam –
This Smart-Ex 01 Intrinsically Safe Cell Phone from Ecom is not as heavy as I thought it would be. The speaker is loud and clear and it works for both private calls and speaker calls. The wifi connection is really great, I used it to download the apps and updates. If you are looking for a rugged cell phone that really works, don’t hesitate in getting this one.
